14/234 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
ABB i-bus® KNX
User Operation – Design Ranges –
Frames

Frames, Dynasty®
For vertical and horizontal installation.

Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
Type code Order code kg pc.
1721-838-500 1-fold, polished brass ivory – 1721-838-500 2CKA001754A4560 0.28 1
1-fold, polished brass – 1721-835-500 2CKA001754A4565 0.28 1
anthracite
1-fold, polished brass decor – 1721-836-500 2CKA001754A4570 0.28 1
ivory
1-fold, polished brass decor – 1721-833-500 2CKA001754A4575 0.286 1
anthracite
1-fold, antique brass ivory – 1721-848-500 2CKA001754A4580 0.28 1
1-fold, antique brass – 1721-845-500 2CKA001754A4585 0.3 1
anthracite
1-fold, antique brass decor – 1721-846-500 2CKA001754A4590 0.3 1
ivory
1-fold, antique brass decor – 1721-843-500 2CKA001754A4595 0.3 1
anthracite
1-fold, ivory – 1721-832-500 2CKA001754A4600 0.042 1
1-fold, anthracite – 1721-831-500 2CKA001754A4605 0.042 1
2-fold, polished brass ivory – 1722-838-500 2CKA001754A4561 0.42 1
2-fold, polished brass – 1722-835-500 2CKA001754A4566 0.42 1
anthracite
2-fold, polished brass decor – 1722-836-500 2CKA001754A4571 0.42 1
ivory
2-fold, polished brass decor – 1722-833-500 2CKA001754A4576 0.42 1
anthracite
2-fold, antique brass ivory – 1722-848-500 2CKA001754A4581 0.44 1
2-fold, antique brass – 1722-845-500 2CKA001754A4586 0.44 1
anthracite
2-fold, antique brass decor – 1722-846-500 2CKA001754A4591 0.42 1
ivory
14
2-fold, antique brass decor – 1722-843-500 2CKA001754A4596 0.44 1
anthracite
2-fold, ivory – 1722-832-500 2CKA001754A4601 0.064 1
2-fold, anthracite – 1722-831-500 2CKA001754A4606 0.064 1
3-fold, polished brass ivory – 1723-838-500 2CKA001754A4562 0.54 1
3-fold, polished brass – 1723-835-500 2CKA001754A4567 0.54 1
anthracite
3-fold, polished brass decor – 1723-836-500 2CKA001754A4572 0.56 1
ivory
3-fold, polished brass decor – 1723-833-500 2CKA001754A4577 0.56 1
anthracite
3-fold, antique brass ivory – 1723-848-500 2CKA001754A4582 0.56 1
3-fold, antique brass – 1723-845-500 2CKA001754A4587 0.54 1
anthracite
3-fold, antique brass decor – 1723-846-500 2CKA001754A4592 0.56 1
ivory
3-fold, antique brass decor – 1723-843-500 2CKA001754A4597 0.56 1
anthracite
3-fold, ivory – 1723-832-500 2CKA001754A4602 0.096 1
3-fold, anthracite – 1723-831-500 2CKA001754A4607 0.096 1
Continuation of table “Frames, Dynasty®” on next page
