ABB i-bus® KNX
User Operation – Design Ranges –
Frames

Frames, future® linear
For vertical and horizontal installation.

Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
Type code Order code kg pc.
1-fold, anthracite – 1721-181K 2CKA001754A4240 0.024 10
1721-184K
1-fold, savanna/ivory – 1721-182K-500 2CKA001754A4506 0.024 10
1-fold, aluminium silver 1) – 1721-183K-500 2CKA001754A4529 0.024 10
1-fold, davos/studio white – 1721-184K-500 2CKA001754A4498 0.024 10
1-fold, studio white, matt 1) – 1721-884K-500 2CKA001754A4531 0.024 10
1-fold, black matt 1) – 1721-885K-500 2CKA001754A4532 0.024 10
2-fold, anthracite – 1722-181K 2CKA001754A4241 0.041 10
2-fold, savanna/ivory – 1722-182K 2CKA001754A4231 0.041 10
2-fold, aluminium silver 1) – 1722-183K-500 2CKA001754A4530 0.04 10
2-fold, davos/studio white – 1722-184K-500 2CKA001754A4499 0.041 10
2-fold, studio white, matt 1) – 1722-884K 2CKA001754A4415 0.037 10
–
2-fold, black matt 1) – 1722-885K-500 2CKA001754A4534 0.037 10
3-fold, anthracite – 1723-181K 2CKA001754A4242 0.05 10
3-fold, savanna/ivory – 1723-182K 2CKA001754A4232 0.05 10
3-fold, aluminium silver 1) – 1723-183K-500 2CKA001754A4533 0.052 10
3-fold, davos/studio white – 1723-184K-500 2CKA001754A4502 0.053 10
3-fold, studio white, matt 1) – 1723-884K 2CKA001754A4416 0.052 10
3-fold, black matt 1) – 1723-885K 2CKA001754A4421 0.052 10
4-fold, anthracite – 1724-181K 2CKA001754A4243 0.064 10
4-fold, savanna/ivory – 1724-182K 2CKA001754A4233 0.064 10
4-fold, aluminium silver 1) – 1724-183K 2CKA001754A4309 0.064 10
4-fold, davos/studio white – 1724-184K 2CKA001754A4238 0.064 10
4-fold, studio white, matt 1) – 1724-884K 2CKA001754A4417 0.064 10
4-fold, black matt 1) – 1724-885K 2CKA001754A4422 0.064 10
5-fold, anthracite – 1725-181K 2CKA001754A4244 0.096 1 14
5-fold, savanna/ivory – 1725-182K 2CKA001754A4234 0.114 1
5-fold, aluminium silver 1) – 1725-183K 2CKA001754A4310 0.114 1
5-fold, davos/studio white – 1725-184K-500 2CKA001754A4517 0.112 1
5-fold, studio white, matt 1) – 1725-884K 2CKA001754A4418 0.114 1
5-fold, black matt 1) – 1725-885K 2CKA001754A4423 0.114 1
Surface painted
