ABB i-bus® KNX
User Operation – Design Ranges –
Busch-triton®

Busch-triton® Control Element, 5/10-fold, FM
With intergrated bus coupling unit. With IR interface for Busch-remote controllers. Push but-
ton function: switching/dimming/blind/value sending/light scenes/step-type switch func-
tions. Switch contacts left/right. One freely programmable LED per rocker (red/green/OFF).
With labeling field.

Description Mod. Order details Price Weight Pack
6320/50-24G-500
width 1 piece 1 piece unit
Type code Order code kg pc.
alpha
platinum – 6320/50-20-500 2CKA006320A0032 0.274 1
studio white, high gloss – 6320/50-24G-500 2CKA006320A0034 0.274 1
palladium – 6320/50-260-500 2CKA006320A0040 0.274 1

impuls
champagne metallic – 6320/50-79-500 2CKA006320A0036 0.274 1

future® linear
aluminium silver – 6320/50-83-500 2CKA006320A0038 0.274 1

Busch-triton® Control Element with Room Thermostat and
3/6-fold Switch Sensor, FM
With integrated KNX bus coupler. With labelling field. Rocker switch left/right (switching/
dimming/blind/value sender/light scenes/fan function). Master/slave configuration. With
base-load operation. Control element with room thermostat function for triggering the
heating, ventilation and fan-coil actuators. The controller is a constant room temperature
controller for ventilator convectors (fan coils) in 2-pipe and 4-pipe systems and conventional
6321/38-24G-500
heating or cooling systems. The fan stage can be switched manually or in automatic mode.
To control up to 13 IR channels (RC5) using Busch-Remote control. IR mobile remote control
6010-25 or 6020-.../6021... . Control element: rocker switch left/right. Display elements: One 14
LED per rocker via separate communication object for status (Red/Green/OFF) or orienta-
tion light. Connections: KNX-line: Bus connection terminal. Protection class (Device): IP 20.
Temperature range (Device): – 5 °C to 45 °C.

Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit

Type code Order code kg pc.
alpha
platinum – 6321/38-20-500 2CKA006320A0052 0.169 1
studio white, high gloss – 6321/38-24G-500 2CKA006320A0054 0.169 1
palladium – 6321/38-260-500 2CKA006320A0060 0.169 1

impuls
champagne metallic – 6321/38-79-500 2CKA006320A0056 0.169 1

future® linear
aluminium silver – 6321/38-83-500 2CKA006320A0058 0.169 1
