14/278 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
ABB i-bus® KNX
User Operation – Design Ranges –
Mylos

Binary Input, 2-fold
Device equipped with 2 binary input channels that can be used to interface to KNX system
conventional push-buttons/rocker switches, or auxiliary/technical contacts. Equipped with
LED for functional signaling. Flush-mounted installation.

Description Mod. Order details Price Weight Pack
2CSYK1001C width 1 piece 1 piece unit
Type code Order code kg pc.
white – 2CSYK1001C 2CSYK1001C 0.07 1
black – 2CSYK1001S 2CSYK1001S 0.07 1

Binary Input, 2-fold, with Rocker Switch
Device equipped with: 1 rocker switch; 2 binary input channels that can be used to interface
to KNX system conventional push-buttons/rocker switches, or auxiliary/technical contacts.
LEDs for the functional signaling of the load to which the rocker switch is connected. Flush-
mounted installation.

2CSYK1002C
Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
Type code Order code kg pc.
white – 2CSYK1002C 2CSYK1002C 0.07 1
black – 2CSYK1002S 2CSYK1002S 0.07 1

Binary Input, 2-fold, with Rocker Switches, 2 gang
Device equipped with: 2 rocker switches; 2 binary input channels that can be used to inter-
face to KNX system conventional push-buttons/rocker switches, or auxiliary/technical con-
tacts. LEDs for the functional signaling of the load to which the rocker switch is connected.
Flush-mounted installation.

2CSYK1003C
14
Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
Type code Order code kg pc.
white – 2CSYK1003C 2CSYK1003C 0.07 1
black – 2CSYK1003S 2CSYK1003S 0.07 1

Binary Input, 2-fold, with Rocker Switches, 2 gang, multifunction
Device equipped with: 2 rocker switches; 2 binary input channels that can be used to inter-
face to KNX system conventional push-buttons/rocker switches, or auxiliary/technical con-
tacts. LEDs for the functional signaling of the load to which the rocker switch is connected.
Upper and lower rocker switches can be separeted for switching, dimming, shutter function-
ality. Flush-mounted installation.
2CSYK1023C
Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
Type code Order code kg pc.
white – 2CSYK1023C 2CSYK1023C 1
black – 2CSYK1023S 2CSYK1023S 1
