ABB i-bus® KNX
User Operation – Design Ranges –
Mylos

Thermostat
Standard KNX thermostat equipped with backlight LCD display 4 push buttons on the front-
for the following functionalities (Operating mode switching, Fan-coil speed manual switch-
ing, set-point manual increment/decrement). Possibility to choose different type of control:
2-point ON/OFF, PWM, Continue, Fan- coil.
2CSYK1202C
Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
Type code Order code kg pc.
white – 2CSYK1202C 2CSYK1202C 0.07 1
black – 2CSYK1202S 2CSYK1202S 0.07 1

Universal Dimmer Actuator, 1-fold, 350W, with Rocker Switch
Device with 350 W dimmer and rocker switch. Suitable for inductive and capacitive load with
automatic recognition. Equipped with LED for load functional signaling.Flush-mounted in-
stallation.

Description Mod. Order details Price Weight Pack
2CSYK1205C width 1 piece 1 piece unit
Type code Order code kg pc.
white – 2CSYK1205C 2CSYK1205C 0.07 1
black – 2CSYK1205S 2CSYK1205S 0.07 1

Dimmer 1..10 V, 1-fold, with Rocker Switch
Device equipped with 1/10 V dimmer with rocker switch. Suitable for loads with ballast ad-
justment. Equipped with LED for load functional signaling. Flush-mounted installation.

Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit 14
2CSYK1206C
Type code Order code kg pc.
white – 2CSYK1206C 2CSYK1206C 0.07 1
black – 2CSYK1206S 2CSYK1206S 0.07 1

Transponder Reader, Mylos
The transponder reader is used for access control in the hotel, residential and commercial
sectors (office buildings, business centers, laboratories, etc.). The device is equipped
with two bistable relays (8 A, 250 V AC), one of which can be assigned to control electronic
lock, and three voltage-free, non-optically insulated inputs; the 5-V DC scanning voltage is
available on the COM terminal.
The transponder reader requires a 10...32 V DC/12...24 V AC external power supply to ensure
its operation even with bus voltage failure.

Description Mod. Order details Price Weight Pack
LT/U 1.1.MC width 1 piece 1 piece unit
LT/U 1.1.MS
Type code Order code kg pc.
white – LT/U 1.1.MC 2CSYK5000C 0.1 1
black – LT/U 1.1.MS 2CSYK5000S 0.1 1
