Intrusion Alarm Systems
ABB-secure@home – Arming Devices

Arming Devices

Preconfigured Remote Control
The remote control is a mobile system device used to manage the anti-intrusion system in
the simplest way. It has 5 with symbolic identification.
One key is freely configurable and the other 4 keys are pre-configured with the following
functions: Away mode, Home mode, Disarm and Panic Alarm. One is a service LED that gives
information about the battery level and the communication status with the central unit; the
SAD-W1.1F other four LEDs are used as a feedback regarding the arming (red LED on) or disarming
(green LED on) status of the different system zones. All LEDs flash yellow for 2 seconds
if there is something preventing the correct arming/disarming of the system (e.g. an open
window). All the keys are equipped with LEDs.
Spare lithium button battery, 3V (CR2032) are normally available on the market.

Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
SAD-W3.1F Type code Order code kg pc.
Square, glass black – SAD-W1.1F 2CSY202821R0305 0.07 1
Round, black – SAD-W3.1F 2CSY295161R1058 0.07 1

Remote Control
The remote control is a mobile system device used to manage the anti-intrusion system in
the simplest way. It has 5 fully configurable keys with numerical identification; each of them
can be confiured to arm/disarm the anti-intrusion zones, but also to trigger secial functions
such as anti-theft alarm, panic alarm, first aid alarm. All the keys are equipped with fully con-
figurable LEDs.
Spare lithium button battery, 3V (CR2032) normally available on the market.
SAD-W2.1F
Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
Type code Order code kg pc.
Square, glass black – SAD-W2.1F 2CSY251641R0306 0.07 1
Round, black – SAD-W4.1F 2CSY277102R0301 0.07 1
SAD-W4.1F
