Intrusion Alarm Systems
Conventional Intrusion Alarm Components – Magnetic Contacts

Magnetic contacts monitor windows, doors, hatches or other
access points for their open or closed state. The state is

evaluated by the alarm system to trigger an intrusion alarm.
Compatible systems: Alarm System – GM/A,
ABB-secure@home, KNX.

Magnet Reed Contact Set
For opening surveillance of windows and doors, complete for bolting or drilling. Contents:
1 magnet, 1 reed contact with 4.0 m connection cable LIYY 4 x 0.14 mm , 2 housings, 2 spacer
2
plates, 2 flanges and 4 anti-magnetic fixing screws. VdS class B.

Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
MRS/W
Type code Order code kg pc.
white – MRS/W GHQ3201972R0001 0.1 1
brown – MRS/B GHQ3201972R0002 0.1 1
Saver Set (20 pcs.), white – VMRS/W GHQ3201972R0011 1.99 1
Saver Set (20 pcs.), brown – VMRS/B GHQ3201972R0012 1.99 1

Magnet Reed Contact for Surface/Flush Mounting
The device signals the opening of windows or doors. As flush mounting device, it can be in-
staled in 8 millimetes round holes; to be installed as surface mounting, it needs the provided
adapter.
It must be necessarily connected to a perimeter magnet reed contact detector (SMC-W1.1x)
or to a dual passive IR perimeter motion detector (SMD-W2.1x); for this purpose it is
SMC-W3.1A equipped with a 1.2 meter connection cable.

Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit

Type code Order code kg pc.
white – SMC-W3.1A 2CSY295241R0606 0.12 1
brown – SMC-W3.1D 2CSY295201R0606 0.12 1

Rolling Door Magnet Reed Contact
The device signals the opening of overhead or rolling doors. It must be necessarily con- 17
nected to a perimeter magnet reed contact detector (SMC-W1.1x) or to a dual passive IR pe-
rimeter motion detector (SMD-W2.1x); for this purpose it is equipped with a 1.2 meter con-
nection cable.
It is made of aluminum with high resistance to the transit of heavy vehicles.
SMC-W2.1
The minimum fixing distance is 20 millimeters from ferrous materials and 25 mm from
non-ferrous materials.

Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
Type code Order code kg pc.
– SMC-W2.1 2CSY255341R0602 0.12 1
