17/30 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Intrusion Alarm Systems
ABB Alarm System – GM/A – Signalling Devices/Installation Material

Signalling Devices

Indoor Siren, 12 V DC
Electronic solid-state siren with intermittent tone for alarm purposes in indoor installations.
External dimensions: ø x H = 90 x 37 mm.

Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
SSS Type code Order code kg pc.
– SSS GHV9270001V0001 0.17 1

Siren in Enclosure
An aluminium protective housing with additional protective enamel coating. Protected
against sabotage by a case tamper contact. The alarm inputs are wired onto a terminal strip.
With fixing screw (M4) for potential equalization on the base.
Dimensions: H x W x D = 200 x 205 x 88 mm; Color: RAL 9002 Environmental class III to VdS.

SSF/G
Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
Type code Order code kg pc.
– SSF/G GHQ3050017R0001 1.64 1

Siren with Strobe
An aluminium protective housing with additional protective enamel coating. Protected
against sabotage by a case tamper contact. The alarm inputs are wired onto a terminal strip.
With fixing screw (M4) for potential equalization on the base.
Dimensions: H x W x D = 258 x 205 x 88 mm; Color: RAL 9002 Environmental class III to VdS.

Description Mod. Order details Price Weight Pack
SSF/GB width 1 piece 1 piece unit
Type code Order code kg pc.
– SSF/GB GHQ3050018R0001 1.81 1

Installation Material

Distribution Enclosure, SM
17
For installation of the Bus Module L240/BS.
Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit

Type code Order code kg pc.
Surface mounting, white – SAD/GAP 2CDG220021R0011 0.131 1
SAD/GAP
