Intrusion Alarm Systems
Conventional Intrusion Alarm Components – Technical Detectors
No matter whether they are smoke, gas or water leakage,
the right detector will recognize it.
Gas Detector with Relay Contact NEW
The Gas Detector is used for monitoring gas leakage of domestic and commercial rooms. It
detects gases like propane, methane and butane as well als acetylene, city gas and natural
gas. The detector can be connected to ABB intrusion and fire alarm control panels, as well as
ABB i-bus® binary inputs via a potential-free relay contact. Suitable as a stand-alone device.
TD-C 1.1 An external power supply with 12-24 V DC is required.
Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
Type code Order code kg pc.
– TD-C 1.1 2CDG220023R0011 0.167 1
Water Detector for Detector Groups
A resin-encapsulated water detector with gold-plated Termipoint pins, detects water in-
gress, e.g., pipe fractures, ingress of groundwater and sewage, water damage caused by
washing machines and dishwashers etc. before the damage becomes too expensive.
SWM 4 For operation directly on detector circuits of intrusion alarm panels or security terminals.
Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
Type code Order code kg pc.
– SWM 4 GHQ4030001R0004 0.16 1
Water Detector with Relay, 12 V
Features a potential free changeover contact output, an LED parallel output and a LED dis-
play. The detector resets itself automatically when the affected area dries out. The device
draws its power from an external 10 ... 23 V DC voltage source.
Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
SWM 4/RN
Type code Order code kg pc.
– SWM4/RN GHQ4030001R0012 0.23 1
