18/4 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
AT wall-mounting compact distribution boards
With distribution panels and sheet steel doors

External dimensions
PW GU SU H x W x D in mm Type Order code

For rail mounting devices and terminals, 125 mm DIN rail spacing
2 5 120 824 x 574 x 140 AT52K 2CPX030126R9999
6 144 974 x 574 x 140 AT62K 2CPX030132R9999
7 168 1124 x 574 x 140 AT72K 2CPX030135R9999

AT52K

3 5 180 824 x 824 x 140 AT53K 2CPX030128R9999
(2/1) 6 216 974 x 824 x 140 AT63K 2CPX030133R9999
7 252 1124 x 824 x 140 AT73K 2CPX030136R9999

AT53K
4 5 240 824 x 1074 x 140 AT54K 2CPX030129R9999
(2/2) 6 288 974 x 1074 x 140 AT64K 2CPX030137R9999

AT64K

For rail mounting devices and terminals, 150 mm DIN rail spacing
2 (1/1) 4 96 674 x 574 x 140 AT42M 2CPX030148R9999

AT42M

3 (2/1) 5 180 824 x 824 x 140 AT53M 2CPX030149R9999

AT53M

18
