18/8 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
AL wall-mounting compact distribution boards
Empty cabinets without door

AL wall-mounting compact distribution boards - Empty cabinets without doors
Suitable and prepared to be fitted with CombiLine modules, distribution panels and media panels
I to 125 A
nA
DIN EN 61439-1/-3 (VDE 0660-600-1/-3)
Protection class without door IP30*
Protection class with door IP43
Protection class II, double insulated
Protection class I, earthed in combination with earthing set (accessories)
Sheet steel housing, 1 mm
Color: White, RAL 9016
Media panels (accessories)
Sheet steel and transparent doors (accessories)
Cable entry covers (accessories)
Without N/PE Quick-terminals
With cable fastening/strain relief rail
A ZB43 membrane flange installed on top per field
* For expansion as installation subdistribution with panels or CombiLine modules
