AT wall-mounting compact distribution boards
With panels and transparent doors

External dimensions
PW GU SU H x W x D in mm Type Order code

For rail mounting devices, 125 mm DIN rail spacing
1 4 48 674 x 324 x 140 AT41TE 2CPX071585R9999
5 60 824 x 324 x 140 AT51TE 2CPX071587R9999
6 72 974 x 324 x 140 AT61TE 2CPX071589R9999
AT41TE
2 3 72 524 x 574 x 140 AT32TE 2CPX071584R9999
(1/1)

AT32TE

2 4 96 674 x 574 x 140 AT42TE 2CPX071586R9999
5 120 824 x 574 x 140 AT52TE 2CPX071588R9999
6 144 974 x 574 x 140 AT62TE 2CPX071590R9999

AT52TE

For rail mounting devices, 150 mm DIN rail spacing
1 3 36 674 x 324 x 140 AT41TR3 2CPX071695R9999
4 48 824 x 324 x 140 AT51TR4 2CPX071698R9999
5 60 974 x 324 x 140 AT61TR5 2CPX071702R9999
AT41TR3

2 2 48 524 x 574 x 140 AT32TR2 2CPX071694R9999
3 72 674 x 574 x 140 AT42TR3 2CPX071696R9999
4 96 824 x 574 x 140 AT52TR4 2CPX071699R9999
5 120 974 x 574 x 140 AT62TR5 2CPX071703R9999
6 144 1124 x 574 x 140 AT72TR6 2CPX071705R9999
AT52TR4
3 3 108 674 x 824 x 140 AT43TR3 2CPX071697R9999
(2/1)
4 144 824 x 824 x 140 AT53TR4 2CPX071700R9999
5 180 974 x 824 x 140 AT63TR5 2CPX071704R9999
6 216 1124 x 824 x 140 AT73TR6 2CPX071706R9999

AT63TR5
4 4 192 82 x 1074 x 140 AT54TR4 2CPX071701R9999
(2/2) 18

AT54TR4
