18/20 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
UL compact distribution boards for flush- and hollow-wall mounting
Empty cabinets without door

UL compact distribution boards - empty cabinets without doors
Prepared to be fitted with CombiLine modules, distribution panels and media panels
I to 125 A
nA
DIN EN 61439-1/-3 (VDE 0660-600-1/-3)
Protection class without door IP30* 1
Protection class with door IP31
Protection class II, double insulated
Protection class I, earthed in combination with earthing set ZE12 (accessories)
Sheet steel housing, 1 mm
Color: White, RAL 9016
Media panels (accessories)
Trim frame with sheet steel or transparent door (accessories)
Hollow-wall mounting set for flush-mounting versions (accessory)
Without N/PE Quick-terminals
With cable fastening/strain relief rail
A ZB40 nipple flange attached on top per field
* 1 For an extension as compact distribution board with distribution panels or CombiLine modules
* Leave not less than 2 SU for DIN rail devices behind the closure

18
