TwinLine N 44 floor-standing cabinets
Accessories and meter applications
Unmounted Installed in the cabinet*
Article Unit Type Order code Type Order code
Cover strip* 1
For meter field installation
to cover the mounting points
of the middle support rail in
TZ612 the insulated standing cabinet
For TwinLine H 1 TZ612 2CPX010507R9999 TZ612A 2CPX010796R9999
Inner cladding* 1 1 TZ610 2CPX010505R9999 TZ610A 2CPX010795R9999
For meter fields,
depth = 225 mm
Additional profile for meter
fields with 150 mm connection
compartment at the top,
TZ610 in the insulated cabinet
Mounting set 1 TZ616 2CPX010511R9999 TZ616A 2CPX010799R9999
For installation of meter fields
in standing cabinets per field
width (250 mm) additionally
TZ616 order 1 x TZ616
Touch protection for
earthed cabinets
For single-level meter fields 1 TZ618 2CPX010673R9999 TZ618A 2CPX010800R9999
TZ618 For dual-level meter fields 1 TZ619 2CPX010674R9999 TZ619A 2CPX010801R9999
* Only in conjunction with the factory-installed meter and distributor fields, combination kits or CombiLine modules.
