TwinLine N 55 wall cabinets and floor-standing cabinets
Mounting plates, sheet steel 2 mm, galvanized

Mounting plate Mounting plate
Height Width not mounted mounted in the cabinet* 1
RE BH FB Type Order code Type Order code
4 0 1 TZM104 2CPX010591R9999 TZM104A 2CPX010744R9999
2 TZM204 2CPX010598R9999 TZM204A 2CPX010750R9999
3 TZM304 2CPX010605R9999 TZM304A 2CPX010756R9999
4 TZM404 2CPX010612R9999 TZM404A 2CPX010762R9999
5 TZM504 2CPX010619R9999 TZM504A 2CPX010768R9999
5 1 1 TZM105 2CPX010592R9999 TZM105A 2CPX010745R9999
2 TZM205 2CPX010599R9999 TZM205A 2CPX010751R9999
3 TZM305 2CPX010606R9999 TZM305A 2CPX010757R9999
4 TZM405 2CPX010613R9999 TZM405A 2CPX010763R9999
5 TZM505 2CPX010620R9999 TZM505A 2CPX010769R9999
6 2 1 TZM106 2CPX010593R9999 TZM106A 2CPX010746R9999
TZM306
2 TZM206 2CPX010600R9999 TZM206A 2CPX010752R9999
3 TZM306 2CPX010607R9999 TZM306A 2CPX010758R9999
4 TZM406 2CPX010614R9999 TZM406A 2CPX010764R9999
5 TZM506 2CPX010621R9999 TZM506A 2CPX010770R9999
7 3 1 TZM107 2CPX010594R9999 TZM107A 2CPX010747R9999
2 TZM207 2CPX010601R9999 TZM207A 2CPX010753R9999
3 TZM307 2CPX010608R9999 TZM307A 2CPX010759R9999
4 TZM407 2CPX010615R9999 TZM407A 2CPX010765R9999
5 TZM507 2CPX010622R9999 TZM507A 2CPX010771R9999
8 4 1 TZM108 2CPX010595R9999 TZM108A 2CPX010748R9999
2 TZM208 2CPX010602R9999 TZM208A 2CPX010754R9999
3 TZM308 2CPX010609R9999 TZM308A 2CPX010760R9999
4 TZM408 2CPX010616R9999 TZM408A 2CPX010766R9999
5 TZM508 2CPX010623R9999 TZM508A 2CPX010772R9999
9 5 1 TZM109 2CPX010596R9999 TZM109A 2CPX010749R9999
2 TZM209 2CPX010603R9999 TZM209A 2CPX010755R9999
3 TZM309 2CPX010610R9999 TZM309A 2CPX010761R9999
4 TZM409 2CPX010617R9999 TZM409A 2CPX010767R9999
5 TZM509 2CPX010624R9999 TZM509A 2CPX010773R9999
12 8 1 TZM112 2CPX010940R9999 TZM112A 2CPX010944R9999
2 TZM212 2CPX010941R9999 TZM212A 2CPX010945R9999
3 TZM312 2CPX010942R9999 TZM312A 2CPX010946R9999
4 TZM412 2CPX010943R9999 TZM412A 2CPX010947R9999
5* TZM212 2CPX010941R9999 TZM212A 2CPX010945R9999
TZM312 2CPX010942R9999 TZM312A 2CPX010946R9999
6* TZM312 2CPX010942R9999 TZM312A 2CPX010946R9999
TZM312 2CPX010942R9999 TZM312A 2CPX010946R9999
* In a cabinet with field width 5 and above, two separate mounting plates
* 1 Mounting plate installed at the factory, only in conjunction with empty cabinet
