TwinLine N 55 wall cabinets and floor-standing cabinets
Accessories meter applications

Unmounted Installed in the cabinet*
Article Unit Type Order code Type Order code
Cover strip* 1
For meter field installation to cover the
mounting points of the middle support
rail in the insulated standing cabinet
TZ614
For TwinLine-G 1 TZ612 2CPX010507R9999 TZ612A 2CPX010796R9999
For TwinLine-L 1 TZ613 2CPX010508R9999 TZ613A 2CPX010797R9999
For TwinLine-W 1 TZ614 2CPX010509R9999 TZ614A 2CPX010798R9999
Inner cladding* 1 1 TZ610 2CPX010505R9999 TZ610A 2CPX010795R9999
For meter fields,
depth = 225 - 350 mm
Additional profile for meter fields with
150 mm connection compartment at
the top,
TZ610 in the insulated cabinet

Mounting set 1 TZ616 2CPX010511R9999 TZ616A 2CPX010799R9999
For installation of meter fields
in standing cabinets per field width
(250 mm) additionally order 1 x TZ616
TZ616

Touch protection for earthed cabinets

For single-level meter fields 1 TZ618 2CPX010673R9999 TZ618A 2CPX010800R9999
TZ618 For dual-level meter fields 1 TZ619 2CPX010674R9999 TZ619A 2CPX010801R9999

Cabinet-cabinet connector
5-pole for Cu 12 x 5 mm 1 TZ620 2CPX010793R9999 - -
5-pole for Cu 2 x 12 x 5 mm 1 TZ621 2CPX010794R9999 - -

TZ620

Steel-sheet feed-in housing 1 TZ622 2CPX010448R9999 - -
IP55, RAL7035 ,
For TwinLine meter cabinets, bottom
mounted
For cables up to max. 120 mm 2
For splicing the access lines
With cable clamp rail
H x W x D: 500 x 300 x 225 mm

TZ622

Steel-sheet feed-in housing 1 TZ623 2CPX010449R9999 - -
IP55, RAL7035 , 18
For TwinLine meter cabinets,
side mounted
For cables up to max. 120 mm 2
For splicing the access lines
With cable clamp rail
H x W x D: 500 x 300 x 225 mm
Busbar system Cu 12 x 5 mm, 5-pole
with 1 connector to the busbar system
TZ623 of the meter field

> For further information on feed-in housings, see chapter on meter cabinets
* Only in conjunction with the factory-installed meter and distributor fields, combination kits or CombiLine modules
