Interior expansion system CombiLine N
Connecting terminals for copper rails

Connection
Copper rails cross-
Dimensions section
Article in mm in mm² Unit Type Order code
Connecting terminals 5 1.5 - 16 1 ZK79 2CPX064879R9999
for latching onto copper rails 4 ZK79P4 2CPX062421R9999
With retaining spring
5 ZK79P5 2CPX062631R9999
50 ZK79P50 2CPX062429R9999
ZK79 ZK81 5 4 - 35 1 ZK81 2CPX064881R9999
4 ZK81P4 2CPX062422R9999
5 ZK81P5 2CPX062632R9999
50 ZK81P50 2CPX062431R9999
5 2.5 - 50 1 ZK150 2CPX064860R9999
4 ZK150P4 2CPX062427R9999
ZK150 ZK178
5 ZK150P5 2CPX062633R9999
50 ZK150P50 2CPX062432R9999
5 16 - 70 1 ZK178 2CPX064978R9999
50 ZK178P50 2CPX062622R9999
5 16 - 120 1 ZK157 2CPX064867R9999
ZK87 ZK157 50 ZK157P50 2CPX062437R9999
10 1.5 - 16 1 ZK87 2CPX064887R9999
4 ZK87P4 2CPX062424R9999
50 ZK87P50 2CPX062430R9999
10 16 - 70 1 ZK156 2CPX064866R9999
50 ZK156P50 2CPX062438R9999
ZK154 ZK156
10 16 - 120 1 ZK154 2CPX064864R9999
50 ZK154P50 2CPX062435R9999
Connecting terminals with insertion 12 x 5 16 - 95 1 ZK83 2CPX064883R9999
part 12 x 10 16 - 70 4 ZK83P4 2CPX062423R9999
for assembly from the front
5 ZK83P5 2CPX062655R9999
50 ZK83P50 2CPX062433R9999
ZK83 ZK152 30 x 5 50 - 120 1 ZK152 2CPX064862R9999
30 x 10 50 - 120 20 ZK152P20 2CPX062444R9999
Frame terminals 12 x 5 16 - 150 4 ZK891P4 2CPX062626R9999
for sliding onto copper rails 12 x 10 16 - 150
12 x 5 35 - 185 1 ZK86 2CPX064886R9999
12 x 10 35 - 120
20 ZK86P20 2CPX062434R9999

ZK891P4 ZK86

Attachment clamp 5/10 10 - 95 1 ZK302 2CPX062645R9999
For fastening on copper rail 20 ZK302P20 2CPX062648R9999
5/10 16 - 150 1 ZK303 2CPX062646R9999
20 ZK303P20 2CPX062649R9999
ZK302 5/10 35 - 240 1 ZK304 2CPX062647R9999
18
20 ZK304P20 2CPX062650R9999
Busbar connection terminal 25 1 ZK75 2CPX038220R9999
for connecting with insulating cap

ZK75
