Interior expansion system parts
DIN rails and DIN rail accessories

Article Use for... Unit Type Order code
DIN rail 35 x 15 mm
Wide rail 1: for assembly on
the mounting frame
For EDF and WR mounting frame, with hole
pattern for wire holders ED44/ED45
ED1 1-field width, length 244 mm M(B)K...12/M(B)G1... 1 ED1 2CPX039381R9999
M(B)G41.../ M(B) 30 ED1P30 2CPX062319R9999
A160ALA
2-field width, length 494 mm M(B)U270 1 ED2 2CPX039382R9999
M(B)G2.../M(B)G42...
30 ED2P30 2CPX062320R9999
3-field width, length 744 mm M(B)U370 1 ED3 2CPX039383R9999
M(B)G3.../M(B)G43...
30 ED3P30 2CPX062321R9999
4-field width, length 994 mm – 1 ED4 2CPX039384R9999
30 ED4P30 2CPX062735R9999
By meter _ 1 ED6 2CPX039386R9999
Length 2000 mm 10 ED6P10 2CPX062705R9999
DIN rail 35 x 15 mm
Wide rail 2: for assembly between
the mounting frame
1-field width, length 188 mm M(B)V1.../ M(B)K1... 1 ED51 2CPX039251R9999
M(B)N1...
30 ED51P30 2CPX062322R9999
ED51
2-field width, length 438 mm M(B)V2.../ M(B)K2... 1 ED52 2CPX039252R9999
M(B)K...13/M(B)C2...HS 30 ED52P30 2CPX062323R9999
M(B)N2...
3-field width, length 688 mm M(B)K3... 1 ED53 2CPX039253R9999
M(B)C3..HS/M(B)N3...
30 ED53P30 2CPX062324R9999
4-field width, length 938 mm - 1 ED54 2CPX039254R9999
DIN rail 35 x 15 mm M(B)K...14 1 ED74 2CPX042185R9999
For terminal block modules, vertical,
length 591 mm, module height 600
mm/4RE
DIN rail 35 x 7.5 mm
For assembly on the mounting frame
1-field width, length 244 mm M(B)K1...K 1 ZX21 2CPX039021R9999
ZX21
30 ZX21P30 2CPX062554R9999
2-field width, length 494 mm M(B)K2...K 1 ZX22 2CPX039022R9999
30 ZX22P30 2CPX062555R9999
DIN rail 35 x 7.5 mm
For assembly between the mounting frame

ZX371 1-field width, length 188 mm M(B)K1...K 1 ZX371 2CPX068076R9999
2-field width, length 438 mm - 1 ZX389 2CPX068190R9999
Insulator piece M(B)K...K 2 ZK90P2 2CPX062426R9999
For DIN rails 100 ZK90P100 2CPX068613R9999
35 x 7.5 and 35 x 15 mm
including attachment material
ZK90P2
Mounting bracket M(B)K1...K 2 ZX372P2 2CPX062544R9999
18
For ZK90P2
ZX372P2
