Interior expansion system CombiLine N
Partitions made of sheet steel for WR mounting frame
Height Depth
Article RE BH mm Unit Type Order code
For TriLine cabinets
®
Vertical partitions, sheet steel 12 8 425 1 RZ151 2CPX046561R9999
Not fault arc-proof, 14 10 425 1 RZ155 2CPX046565R9999
WR mounting frame to
WR mounting frame 12 8 625 1 RZ152 2CPX046562R9999
Partition wall is riveted to 14 10 625 1 RZ156 2CPX046566R9999
WR mounting frame
RZ151
Width Depth
Article FB mm mm Unit Type Order code
For TriLine cabinets
®
Horizontal partitions, sheet steel 1 250 425 1 RZ161 2CPX046571R9999
Not fault arc-proof, with additional 2 500 425 1 RZ162 2CPX046572R9999
mounting profile for assembly on
the WR mounting frame 3 750 425 1 RZ163 2CPX046573R9999
1 250 625 1 RZ164 2CPX046574R9999
RZ161
2 500 625 1 RZ165 2CPX046575R9999
3 750 625 1 RZ166 2CPX046576R9999
