Interior expansion system parts
Profile rails and mounting bracket

Article Use for... Unit Type Order code
Transverse rail 3-field width* M(B)T350(B) 1 ZW395 2CPX041136R9999
Busbar carrier M(B)T351(B)
Fixed position M(B)H350(B)
M(B)H351(B)
M(B)R302(B)
ZW395
Transverse rail 3-field width* M(B)R303 1 ZW396 2CPX041137R9999
Busbar carrier position can be moved M(B)S324
if necessary M(B)S327

ZW396

Assembly bracket M(B)H...50 1 ZX343 2CPX064152R9999
For busbar modules S700 and S750
For EDF or WR mounting frame
ZX343 ZX334
For modules for line connection M(B)V...80 1 ZX334 2CPX064166R9999
For lowering DIN rails M(B)V...81
For EDF or WR mounting frame
Deep angle piece M(B)D...52(B) 4 ZW480 2CPX042239R9999
For busbar module equipment 100 mm
With 3-stage adjustability
For EDF or WR mounting frame
For busbar module equipment 185 mm M(B)D...21-300(B) 4 ZW481 2CPX042195R9999
ZW480 ZW481 With 2-stage adjustability
For WR mounting frame

Bracket with NH + EFM cover M(B)D...21-300(B) 2 ZW482 2CPX042196R9999
For busbar module equipment 185 mm
For WR mounting frame

ZW482
45° inclined for busbar module M(B)S...28 1 ZX321LR 2CPX064160R9999
For EDF or WR mounting frame
For busbar module 40/60 mm M(B)S...24 1 ZW389LR 2CPX062635R9999
When using ZB5/ZX151 M(B)S...27
ZX321LR ZW389LR For WR mounting frame
For busbar carrier ZX520 - 1 ZX342 2CPX062661R9999
For WR mounting frame
For busbar module equipment 185 mm ML100 - ML300 1 ZW349 2CPX067951R9999
For WR mounting frame ML21B - ML33B 10 ZW349P10 2CPX062485R9999
ZX342 ZW349

For attaching transverse profiles WR...8 1 ZW64 2CPX039464R9999
on the WR frame WR...10 40 ZW64P40 2CPX062475R9999
including attachment material
