Subdistribution boards
CombiLine S for switch disconnector OT, horizontal

OT switch disconnector horizontal
• Unequipped set for ABB OT...E03/04P as an
incomer or outgoing switch
• Sheet steel cover with cut out for rotary handle
in top of the center
• Cover fixed with one 1/4 turn quick-lock
• Important: in case of using switch disconnectors OT630
and OT800 it is not possible to use busbar system
CHCQ1513 CHDQ1513
behind the mounting plate
For device Order details
Width Height Numbers of Numbers Minimum
mm mm I max A Type breakers of poles cabinet depth Type Order code Price Pcs.
n
600 350 400 OT200, OT250, 1 3/4 225 CHCQ1513 2CPX078302R9999 1
OT315, OT400
500 800 OT630, OT800 1 3/4 275 CHCR1513 2CPX078377R9999 1
800 350 400 OT200, OT250, 1 3/4 225 CHDQ1513 2CPX078303R9999 1
OT315, OT400
500 800 OT630, OT800 1 3/4 275 CHDR1513 2CPX078378R9999 1
