Subdistribution boards
CombiLine S for switch disconnector OT, vertical

OT switch disconnector vertical left
• Unequipped set for ABB OT...E03/04P as an
incomer or outgoing switch
• Sheet steel cover with cut out for rotary handle
on the left side
• Cover fixed with one 1/4 turn quick-lock
• Important: in case of using switch disconnectors OT630
and OT800 it is not possible to use busbar system
CVAP1513 CVDQ1513
behind the mounting plate
For device Order details
Width Height Numbers of Numbers Minimum
mm mm I max A Type breakers of poles cabinet depth Type Order code Price Pcs.
n
300 350 250 OT200, OT250 1 3/4 225 CVAP1513 2CPX078304R9999 1
600 350 400 OT200, OT250, 1 3/4 225 CVCQ1513 2CPX078305R9999 1
OT315, OT400
500 800 OT630, OT800 1 3/4 275 CVCR1513 2CPX078379R9999 1
800 350 400 OT200, OT250, 1 3/4 225 CVDQ1513 2CPX078306R9999 1
OT315, OT400
500 800 OT630, OT800 1 3/4 275 CVDR1513 2CPX078380R9999 1

OT switch disconnector vertical center
• Unequipped set for ABB OT...E12/22P as an
incomer or outgoing switch vertical
• Sheet steel cover with cut out for rotary handle
in the center
• Cover fixed with 1/4 turn quick-lock
• Important: in case of using switch disconnectors OT630
CVAP1514 CVDQ1514
and OT800 it is not possible to use busbar system
behind the mounting plate

For device Order details
Width Height Numbers of Numbers Minimum
mm mm I max A Type breakers of poles cabinet depth Type Order code Price Pcs.
n
300 350 250 OT200, OT250 1 3/4 225 CVAP1514 2CPX078307R9999 1
600 350 400 OT200, OT250, 1 3/4 225 CVCQ1514 2CPX078308R9999 1
OT315, OT400
500 800 OT630, OT800 1 3/4 275 CVCR1514 2CPX078381R9999 1
800 350 400 OT200, OT250, 1 3/4 225 CVDQ1514 2CPX078309R9999 1
OT315, OT400
500 800 OT630, OT800 1 3/4 275 CVDR1514 2CPX078382R9999 1
