Subdistribution boards
Examples of configurations

+0
1
+01 ESBN0610 +02 ESBN0310
CACP40100
CKUC6020
+02.10
+01.10 CVAA1511
CKDD1620 ABB TMax XT1
+02.20
+01.20
CKDD1620 CACP4060
+01.40
CKBS1233
+02.30
CKDD1620
+01.30
CACP6020

+01.50 +02.40

TwinLine S 43 (1000 x 600 x 225 mm + 1000 x 300 x 225 mm) IP43
Internal configuration CombiLine S, with busbars 250 A, 10 kA in external cable container
Type Ord.no. Description Pcs.
ESBN0610 2CPX078112R9999 Rear wall, W 600 mm , H 1000 mm 1
ESPG0600 2CPX078146R9999 Top/bottom plate (open/closed), D 225 mm , W 600 mm 1
ESSG0010 2CPX078130R9999 Side walls 2 pcs, D 225 mm , H 1000 mm 1
ESAT0610 2CPX078180R9999 Transparent door, W 600 mm , H 1000 mm 1
ESBN0310 2CPX078103R9999 Rear wall, W 300 mm , H 1000 mm 1
ESPG0300 2CPX078145R9999 Top/bottom plate (open/closed), D 225 mm , W 300 mm 1
ESIN0010 2CPX078423R9999 Installation set for internal configuration, H 1000 mm 2
ESUG0010 2CPX078226R9999 Upright cabinet connection, D 225 mm , H 1000 mm 1
ESAS0310 2CPX078154R9999 Sheet steel door, W 300 mm , H 1000 mm 1
TZ101 2CPX010450R9999 Flange for 52 entries 3

CKDC1620 2CPX078321R9999 CombiLine S, DIN Components, Row distance 200 mm , 1 row, W 600 mm , H 200 mm 3
CACP6020 2CPX078353R9999 CombiLine S, Cover, plain, W 600 mm , H 200 mm 1
CKUC6020 2CPX078314R9999 CombiLine S, Measuring instruments, 4 pcs. 72x72 mm , W 600 mm , H 200 mm , 1
CVAC1511 2CPX078269R9999 CombiLine S, Device vertical, W 300 mm , Tmax XT3, 1 device, 3/4 pole, fixed, lever 1
operation
CACP3060 2CPX078348R9999 CombiLine S, Cover, plain, W 300 mm , H 600 mm 1 18
CACP3010 2CPX078341R9999 CombiLine S, Cover, plain, W 300 mm , H 100 mm 1
CASWP2 2CPX078454R9999 CombiLine S, Support, wiring duct, 2 pcs 3
CAHW6 2CPX078459R9999 CombiLine S, Mounting profile, for wiring system, W 600 mm 3
CKBS1231 2CPX078449R9999 CombiLine S, Busbar, support, flat busbars, holder scaled, W 300 mm , 1 support 3

BR0250 No. 2 flat busbars 250 A 1
