19/18 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Consumer units
N/PE screw terminals

Configure based on your needs Product benefits
The modularity and the extensive range of products allow • Flexible terminal system for several N potentials:
customizing the new products to the needs based on real- Screw connections: 1.5 to 16 mm² for rigid conductors;
2
world use. Various terminals can be combined on one com- for flexible conductors up to 16 mm
mon carrier as necessary. (wire end sleeves required)
• Optimal when using several residual current circuit
breakers
• Precise assignment of the terminals by
clear colour coding: N = blue, PE = yellow-green
• Easy labelling of the terminals using pre-printed,
self-adhesive number strips
• Wide range of applications: may be used in the UK600
and MISTRAL65 consumer unit series, in all compact
distribution boards, and with all meter cabinets,
wall-mounting and floor-standing cabinets

Screw Screw
N/PE terminals N connection PE connection
with units screw-terminals system screw-terminals system

1 2 3
ZKS6B 3 x 6 mm 2 3 x 16 mm 2 ZKS6G 3 x 6 mm 2 3 x 16 mm 2

1 2 3 4 5
ZKS11B 5 x 6 mm 2 5 x 16 mm 2 ZKS11G 5 x 6 mm 2 5 x 16 mm 2

1 2 3 4 5 6 7 ZKS16B 9 x 6 mm 2 7 x 16 mm 2 ZKS16G 9 x 6 mm 2 7 x 16 mm 2
19

1 2 3 4 5 6 7 8 9
ZKS21B 12 x 6 mm 2 9 x 16 mm 2 ZKS21G 12 x 6 mm 2 9 x 16 mm 2

11 x 16 11 x 16
1 2 3 4 5 6 7 8 9 10 11
ZKS26B 15 x 6 mm 2 mm 2 ZKS26G 15 x 6 mm 2 mm 2
