Consumer units
UK600 basic version without trim frame and door

Article H x W x D (mm) SU Type Ord. no.
Flush-mounted consumer units, 1-row
Niche dimensions for flush-mounting 355 x 367 x 95 12 UK612NB 2CPX031374R9999
Wall cut out dimensions for hollow-wall- 328 x 340 x 88 (13)
mounting
With N/PE quick-terminals:

UK612NB ZK51B, ZK82B, ZK113G
Flush-mounted consumer units, 2-row
Niche dimensions for flush-mounting 480 x 367 x 95 24 UK624NB 2CPX031375R9999
Wall cut out dimensions for hollow-wall- 453 x 340 x 88 (28)
mounting
With N/PE quick-terminals:
ZK51B, ZK82B, ZK144G

UK624NB
Flush-mounted consumer units, 3-row
Niche dimensions for flush-mounting 605 x 367 x 95 36 UK636NB 2CPX031376R9999
Wall cut out dimensions for hollow-wall- 578 x 340 x 88 (41)
mounting
With N/PE quick-terminals:
ZK51B, 2 x ZK113B, ZK206G

UK636NB
Flush-mounted consumer units, 4-row
Niche dimensions for flush-mounting 730 x 367 x 95 48 UK648NB 2CPX031377R9999
Wall cut out dimensions for hollow-wall- 703 x 340 x 88 (56)
mounting
With N/PE quick-terminals:
2 x ZK82B, ZK144B, ZK237G

UK648NB

Flush-mounted consumer units, 5-row
Niche dimensions for flush-mounting 855 x 367 x 95 60 UK660NB 2CPX031378R9999
Wall cut out dimensions for hollow-wall- 828 x 340 x 88 (70)
mounting
With N/PE quick-terminals:
ZK51B, 2 x ZK82B, ZK144B, ZK268G

UK660NB
