20/12 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Automation boards
Basic configuration - Gemini switchboards

In the basic configuration, Gemini switchboards are lock that can be replaced by locks of another type available
composed of boxes in six different sizes ranging from in the accessories. Boxes and doors can be requested either
335x400x210 mm to 840x1005x360 mm (WxHxD, external separately or as combined “box + door” codes, to make
measurements) and with opaque or transparent doors. In filling out the order form more flexible. Inside the packages,
both versions, the doors are reversible and clip onto the the door is always wrapped separately and inserted inside
hinges without the need to use tools; the fact that they open a pocket that protects it from accidental damage until
at an angle of more than 180° means that it is easy to work wiring is completed and the switchboard is installed.
on the components installed inside the switchboard. Hole-cover plugs to guarantee IP protection and double
The seal applied by extrusion along the sides of the doors insulation for wall mounting are also supplied with the pack
guarantees IP66 degree of protection. Access to the inside together with the instruction sheet.
of the switchboard is protected by a standard double bit

Specifications
Protection IP66 (IEC EN 60529)
Class II insulation
Strength Thermoplastic material moulded in co-injection
Resistance to abnormal heat and fire up to a temperature of 750 °C (IEC EN 60695-2-11)
IK10 (IEC EN 50102) degree of resistance to impacts
Protection against chemical and atmospheric agents (water, saline solutions, acids, basic agents, mineral oils, UV rays)
Operating temperature -25 °C ÷ +100 °C
Performances Rated service voltage up to 1000 V
Rated insulating DC voltage up to 1000 V
Rated insulating AC voltage up to 1500 V
Flexibility of use 6 sizes from 335x400x210 mm to 840x1005x360 mm (WxHxD, external dimensions)
DIN 24 to 216 modules
Installation Snap-on mounting of all components in compliance with safety Standards
Quality and environment Compliance with CEI EN 62208 international reference Standard,
qualification for the requirements of CEI EN 61439-1 Standard, IMQ mark according to EN 62208 Standard.
100% recyclable
EN 60068-2-52 resistance to marine environments
EN60068-2-5 resistance direct sun exposure
UL Listed: UL508A, UL50, UL50E
Nema: Types 1, 3R, 4, 4X, 12

Gemini doors open at an angle of more No tools are needed for installation. The special structure of the inner
than 180° giving easy access to the de- The doors hook onto the hinges with perimeter of the box ensures further
vices installed inside the switchboard. special hinge pins and are reversible. protection against the penetration of
water. The box is supplied with a spirit
level.
