Automation boards
Components for automation applications

Base plates
• Available in three versions in blank or drilled metal and insulating material
• Positioning at 3 different depths for size 1, 4 different depths for sizes 2-3-4 and 7 differ-
ent depths for sizes 5-6 (adjustments with 30 mm pitch)
• Supplied with feet and hooks adjustable at three further positions (with 7.5 mm pitch)
• Snap-on mounting
• Plates can also be mounted directly on the base with the special kit.

Blank metal
Size of the switchboard Code Unit/Pack
1 1SL0259A00 1/6
2 1SL0260A00 1/6
3 1SL0261A00 1/4
4 1SL0262A00 1/4
5 1SL0263A00 1/4
6 1SL0264A00 1/2
Blank metal base plate
Drilled metal
Size of the switchboard Code Unit/Pack
1 1SL0275A00 1/6
2 1SL0276A00 1/6
3 1SL0277A00 1/4
4 1SL0278A00 1/4
5 1SL0279A00 1/4
6 1SL0280A00 1/2

Drilled metal base plate
Insulating material
Size of the switchboard Code Unit/Pack
1 1SL0267A00 1/6
2 1SL0268A00 1/6
3 1SL0269A00 1/4
4 1SL0270A00 1/4
5 1SL0271A00 1/4
6 1SL0272A00 1/2

Insulating material base plate Description Code Unit/Pack
Base mounting kit for metal plate 1SL0383A00 1/10
