ABB MOTOR PROTECTION AND CONTROL 3/331

—

Spare parts contactors
Contactor coils, main contact sets and arc chutes

Electronic Modules 03
Control circuit electronic module spare part.
Rated contol circuit Type Pkg Weight
Voltage Uc qty (1 pce)
V 50/60Hz V DC kg
4-pole contactors
AF116 24…60 20…60 ZPT116-11 1SFN164224R1011 1 0.149
48…130 48…130 ZPT116-12 1SFN164224R1012 1 0.149
100…250 100…250 ZPT116-13 1SFN164224R1013 1 0.153
250…500 250…500 ZPT116-14 1SFN164224R1014 1 0.165
AF140 24…60 20…60 ZPT140-11 1SFN164424R1011 1 0.149
48…130 48…130 ZPT140-12 1SFN164424R1012 1 0.149
100…250 100…250 ZPT140-13 1SFN164424R1013 1 0.153
250…500 250…500 ZPT140-14 1SFN164424R1014 1 0.165
AF190, AF205 24…60 20…60 ZPT205-11 1SFN165224R1011 1 0.618
48…130 48…130 ZPT205-12 1SFN165224R1012 1 0.620
100…250 100…250 ZPT205-13 1SFN165224R1013 1 0.626
250…500 250…500 ZPT205-14 1SFN165224R1014 1 0.636
AF265, AF305, AF370 24…60 20…60 ZPT370-11 1SFN166024R1011 1 0.706
48…130 48…130 ZPT370-12 1SFN166024R1012 1 0.716
100…250 100…250 ZPT370-13 1SFN166024R1013 1 0.710
250…500 250…500 ZPT370-14 1SFN166024R1014 1 0.720
Note: Only suitable for AF116...AF370 contactors "Made in Sweden" produced after 2018-09-01 (010918).

Arc chutes
For contactors Type Order code Pkg Weight
qty (1 pce)
kg
AF400, AF460 ZW460 1SFN165710R1000 1 1.380
AF580, AF750, AF1250 ZW750 1SFN166110R1000 1 1.500
AF1350, AF1650, AF2050 ZW1650 1SFN166510R1001 1 4.560
AF2650 ZW2650 1SFN166610R1000 1 4.000
