11/56 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Busch-dynasty®
Dimmers

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

3
4
2
Busch-rotary dimmer ) ) ) ) ) ) Busch-rotary dimmer ) ) ) )
1
6
3
2
4
1
5
flush mounted, RC, 40-420 W flush mounted, 1-10V
DP switched With rotary control.
With rotary control, soft-catch and with trailing edge For controlling ballast units for fluorescent lamps with
control. For incandescent lamps, 230 V tungsten control output 1-10 V DC, control current max. 50 mA DC.
halogen lamps and low-voltage halogen lamps with For LED control via control gears
electronic transformers. Low-noise, short-circuit-proof, Without cover plate.
overload-protected. Without cover plate. Rated voltage: 230 V~, +10 % / -10 %
DP cut off (P,N) Rated frequency: 50 Hz - 60 Hz
Rated voltage: 230 V~, +10 % / -10 % Rated power: 700 W/VA
Rated frequency: 50 Hz IEC 60669-2-1, British Standard EN 60669-2-1
Rated power: 20 - 420 W/VA
IEC 60669-2-1, British Standard EN 60669-2-1
2112 U-101-500 2CKA006599A2873 1/10
1) Non-illuminable.
2) Use cover plates 2115 J-.../2115-.../6540-... .
6514 U-500 2CKA006514A0115 1 3) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
1) Not suitable with conventional transformers. Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
2) Illuminable with neon lamp. Neon lamp included in delivery with cover plate. or 3060 wallbox concrete)
3) In case of electronic transformers, 5 % transformer losses. 4) Making-current limiters have to be provided in case of too high making currents.
4) Provided with terminal for net disconnection devices.
5) Also applicable for 1gang 2way installations.
6) Only in conjunction with standard flush-mounting boxes according to DIN 49073, Busch-rotary dimmer )
1
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall Flush-mounted, DALI, tunable white
or 3060 wallbox concrete) For DALI broadcast service (via central telegram).
For switching and dimming up to 64 DALI- devices
like electronic ballasts and transformers with DALI-
3
5
4
Busch-rotary dimmer ) ) ) ) )
2
1
11
flush mounted, RLC, 60-420 W interface.
with soft-catch With rotary control and ON/OFF push operation.
With intelligence for universal operation. Fool proved.
For incandescent lamps, 230 V tungsten halogen lamps For changing the colour temperature of "tunable white"
and low-voltage halogen lamps with conventional lamps, which meet DALI Standard IEC 62386-209 (Device
transformers or electronic transformers. Type 8).
Short-circuit-proof, overload-protected. Colour temperature can then be set between 2,700 K -
Capacity expansion via output-side, parallel connectable 6,500 K.
load line with a power module 6594 U up to 735 W/VA Brightness power-on level and backround brightness
possible. Operation via rotary-type remote control level adjustable, buffered.
6592 U possible. Without cover plate. With integrated LED illumination for orientation.
Rated voltage: 230 V~, +10 % / -10 % Color of orientation light adjustable (18 presets and
Rated frequency: 50 Hz - 60 Hz OFF).
Rated power: 60 - 420 W/VA Up to 5 potentiometers are connectable in parallel.
IEC 60669-2-1, British Standard EN 60669-2-1 Max. current consumption: 15 mA.
Not suitable for combining with other DALI sensors or
central units of other manufacturers.
For the generation of the DALI voltage a power supply
6591 U-101-500 2CKA006513A0588 1/10 according to IEC 62386 is required; e.g. from Tridonic,
1) Illuminable with neon lamp 3855. Neon lamp included in delivery with cover plate. Philips, Helvar or BJE article no. 2116/11 U.
2) In case of electronic transformers, 5 % transformer losses. Max. DALI-cable length: 300 m (1,5 - 2,5 mm²).
3) In the case of conventional transformers, take ~20% transformer loss into account. Without cover plate.
4) Only in conjunction with standard flush-mounting boxes according to DIN 49073, Protection class (Device): IP 20
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall Temperature range (Device): 0 °C to 35 °C
or 3060 wallbox concrete)
5) Cannot be combined with a 2way switch. 2116 U 2CKA006599A3025 1
1) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
Busch-rotary dimmer, extension ) ) 2 Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
1
or 3060 wallbox concrete)
flush mounted
for connection to 6591 U-101,
To be used with Busch-Dimmer®, MDRC 6583.
with soft-catch
A maximum of 5 multi-way extensions can be connected
to a 6591U-101,
Without cover plate.
Rated voltage: 230 V~, +10 % / -10 %
Rated frequency: 50 Hz - 60 Hz

6592 U-500 2CKA006513A0590 1
1) Control elements 2115-xxx and 6540-xxx.
2) Required for illuminating the N-connection control element.
