11/60 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Busch-dynasty®
Movement detectors / comfort switches

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Busch-Universal relay switch insert Busch-Watchdog relay mechanism
3 wire connection (neutral conductor required). 3 wire connection (neutral conductor required).
For Busch-Watchdog 180 flush-mounted Sensor For Busch-Watchdog 180 flush-mounted Sensor
Standard 6810-21x-101. For Busch-Watchdog 180 Standard 6810-21x-101.
flush-mounted sensor Comfort II 6800-xxx-104 and For Busch-Watchdog 180 flush-mounted sensor
6800-xxx-104M. For Busch-Watchdog 180 FP sensor Comfort II 6800-xxx-104 and 6800-xxx-104M.
for All Weather 44 6800-3x-102C. For Busch-Watchdog For Busch-Watchdog Presence tech 6813-xxx-101 und
Presence tech 6813-xxx-101 und 6813/11-xxx. 6813/11-xxx.
For comfort timer control element 6455-101-500. Rated voltage: 230 V, +10 % / -10 %
For Busch-Remote control IR control cover 6067-xxx-10x. Rated frequency: 50 Hz
For control cover with control lamp 6543-xxx-10x. Outputs: 1x Normally open contact, potential-bound
Combinable with Busch-Watchdog extension insert Suitable for: 230 V incandescent lamps, 230 V halogen
6805 U. Operation also possible via conventional push lamps, fluorescent lamps and low-voltage halogen
buttons (2020 US, 2021/6 UK). lamps, that are operated via transformers.
Rated voltage: 230 V~, +10 % / -10 % Rated power: 700 W/VA
Rated frequency: 50 Hz
Outputs: 1x Normally open contact, potential-bound Temperature range (Device): 0 °C to 55 °CBritish
Suitable for: 230 V incandescent lamps, 230 V halogen Standard EN 60669-2-1
lamps, fluorescent lamps and low-voltage halogen
lamps, that are operated via transformers.
Rated current: 10 AX 6812 U-101-500 2CKA006800A2160 1/10
Rated power: 2300 W/VA
2
1
6
Busch-Watchdog MOS-Fet Insert ) ) ) ) ) )
5
3
4
Temperature range (Device): -25 °C to 55 °C60669-2-1 2-wire connection (neutral conductor not required)
For Busch-Watchdog 180 flush-mounted Sensor
6401 U-102-500 2CKA006401A0049 1/10 Standard 6810-21x-101.
For Busch-Watchdog 180 flush-mounted sensor
11
Comfort II 6800-xxx-104 and 6800-xxx-104M.
Busch-Universal 2gang 1way insert For Busch-Watchdog Presence tech 6813-xxx-101 und
3 wire connection (neutral conductor required). 6813/11-xxx.
For the serial switch operating mode: 2 separate Combinable with Busch-Watchdog extension insert
outputs, 2 separate extension inputs. 6805 U.
For operation mode timer: output 1 (eg lighting), Operation also possible via conventional push buttons
output 2: ON/Off delay in dependence of output 1 (eg (2020 US, 2021/6 UK).
fan control). For Busch-Watchdog 180 flush-mounted Rated voltage: 230 V~, +10 % / -10 %
Sensor Standard 6810-21x-101. For Busch-Watchdog Rated frequency: 50 Hz
180 flush-mounted sensor Comfort II 6800-xxx-104 and Suitable for: 230 V incandescent lamps, 230 V halogen
6800-xxx-104M. For Busch-Watchdog Presence tech lamps and low-voltage halogen lamps with conventional
6813-xxx-101 und 6813/11-xxx. transformers or Busch Electronic Transformer.
For Busch-Remote control IR control cover 6066-xxx-10x Rated power: 60 - 420 W/VA
and 6067-xxx-10x.
For control cover 6430-xxx-10x and 6543-xxx-10x. Temperature range (Device): 0 °C to 35 °CBritish
Combinable with Busch-Watchdog extension insert Standard EN 60669-2-1
6805 U.
Operation also possible via conventional push buttons
(2020 US, 2021/6 UK). 6804 U-101-500 2CKA006800A2219 1/10
Rated voltage: 230 V~, +10 % / -10 % 1) In case of electronic transformers, 5 % transformer losses.
Rated frequency: 50 Hz 2) In the case of conventional transformers, take ~20% transformer loss into account.
Outputs: 2x Normally open contact, potential-bound 3) Not suitable for the activation of energy-saving lamps, conventional and electronic
ballast units and LED lamps.
Suitable for: 230 V incandescent lamps, 230 V halogen 4) Not suitable for activating the staircase time delay.
lamps, fluorescent lamps and low-voltage halogen 5) Cannot be used to control relais.
lamps, that are operated via transformers. 6) Requires an NIS international socket, E-No. 372507676.
Rated current: 10 AX
Rated power: 2300 W/VA
Temperature range (Device): 0 °C to 35 °CBritish
Standard EN 60669-2-1

6402 U-500 2CKA006401A0051 1/10
Mounting 35 mm deep flush 1gang
boxes: or Dual Box 3070-2/35 BSDB.
2gang product 2gang combination with adapter plate
combinations: APBS in Dual Box only.
neon indicator: neon lamp 3855, one neon lamp is supplied together with
control cover plates 6540-2x.
