11/62 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Busch-dynasty®
Movement detectors / comfort Blind control / timers
switches

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

2
1
Universal-Slave insert Key Switch Insert ) ) )
3
3 wire connection (neutral conductor required). breaking circuit, 1-pole
For the extension of Busch-Comfort switch or Busch- For profile semi-cylindrical lock.
Presence detector installations. In switched-on and switched-off status the key can be
For communication with Universal relay insert pulled out in the central position, respectively.
6440/01 U-500. Delivered without cylindrical lock.
For communication with Universal-e-contact insert Rated voltage: 250 V~
6440/04 U-500. Rated current: 10 AX
For Busch-Comfort switch control element Protection class (Device): IP 20IEC60669-1, British
6815-...-101-500. Standard EN 60669-1
For Busch-Presence detector sensor 6813-…-102-500. 2733 USL-101 2CKA001101A0914 10
Rated voltage: 230 V~, +10 % / -10 %
Rated frequency: 50 Hz - 60 Hz Mounting 35 mm deep flush 1gang
Control/Signal outputs: 1, electronic output, potential- boxes: or Dual Box 3070-2/35 BSDB.
bound 2gang product 2gang combination with adapter plate
Temperature range (Device): -5 °C to 45 °C combinations: APBS in Dual Box only.
Dimensions: (L x W x D): 71 mm x 71 mm x 32 mm
Mounting depth: 31 mm neon indicator: not applicable
delivery form: Adapter plate APBS to be ordered separate.
6440/05 U-500 2CKA006400A0091 1
1) For installation on British Standard wallboxes please use adapter plate APBS
(6599-0-2813). (Depth of box 60 mm.)
Busch-Comfort switch control element ) ) 2) Use the cylindrical lock according to the enclosed drawing.
2
1
with neon lamp 3) See profile semi-cylindrical lock.
Movement detector/push-button switch combination.
Push switch function possible at all times.
2
1
For switching lighting systems that depend on Blind switch insert ) )
brightness and movement. With interlock.
11
Extension of the detection range by means of master/ Rated voltage: 250 V~
slave combination. Rated current: 10 AX
Additional activation/deactivation possibility through Protection class (Device): IP 20IEC60669-1, British
pushbutton input. Standard EN 60669-1
Adjustable operating mode: automatic mode, automatic
(motion-controlled) switch-on and switch-off. SP, switch
Adjustable operating mode: semiatuomatic, manual
switch-on, automatic (time and motion-controlled) 2000/4 US-500 2CKA001012A2197 10/100
switch-off.
Adjustable operating mode: automatic switch-on, SP, push switch.
manual switch-off. 2020/4 US-500 2CKA001413A1103 10/100
With continuous light/continuous off function.
Adjustment elements on the rear. 1) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
Surveillance density: 9 sectors with 28 switching Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
segments. or 3060 wallbox concrete)
Switch-off delay: 1 to 10 min., adjustable. 2) These blind switches/push buttons safely prevent a switch-over of the running
direction being carried out too quickly.
For Busch-Universal relay switch insert 6440/01 U-500.
For Universal-e-contact insert 6440/04 U-500.
For Universal-Slave insert 6440/05 U-500. Blind switch insert ) )
2
1
Control element: 2 controllers for setting the brightness With rotary knob/switch and push switch.
switching threshold and switch-off delay. Rated voltage: 250 V~
Display elements: LED for status display. Rated current: 10 AX
Detection range: frontal: 5 m, lateral: 3 m, Mounting Protection class (Device): IP 20
height: 1.1 m IEC 60669-1, British Standard EN 60669-1
Detection angle: 170 °
Brightness limit value: 0.5 Lux - 500 Lux , Daytime
3
operation DP )
Mounting height: 0.8 m - 1.2 m 2712 U 2CKA001101A0534 10
Protection class (Sensor): IP 20
Temperature range (Device): 0 °C to 35 °C SP, N, E
Dimensions: (L x W x D): 63 mm x 63 mm x 28.3 mm
DIN EN 60669-2-1 2713 U 2CKA001101A0542 10
anthracite 6815-81-101-500 2CKA006800A2828 1 Mounting 35 mm deep flush 1gang
boxes: or Dual Box 3070-2/35 BSDB.
ivory white 6815-82-101-500 2CKA006800A2830 1
2gang product 2gang combination with adapter plate APBS in Dual Box
antique brass 6815-840-101-500 2CKA006800A2841 1
combinations: only.
1) Please order the respective flush-mounted insert separately.
2) The range specifications refer to an ambient temperature of 21 °C. neon indicator: not applicable
3) Surface painted. delivery form: Adapter plate APBS to be ordered separate.
1) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
or 3060 wallbox concrete)
2) Blind switches/push switches prevents fast change over between operating
directions.
3) Also suitable for controlling direct voltage drives.
