11/105

—
pure stainless steel
Blind control / timers

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Cover plate ) ) Comfort timer control element )
1
2
1
with rotary knob For manual and time-controlled switching of blinds,
For comfort blinds insert 6419 U. roller blinds, awnings, lighting and other electrical
Surface painted. devices.
With dusk to dawn program including (Astro-program)
Individual Astro adjustment and Astro blocking time.
The controlled devices can be manually operated at any
stainless steel 6436-866 2CKA006430A0362 10 time.
1) Continuous lighting of the turn knob possible using glow lamp 3855. Not included Simple setting via high-resolution display with
in delivery. Neutral wire required for operation with neon lamp. background illumination.
2) Surface painted.
With preset switching times/date/time.
Factory-set switching times can be individually
adjusted.
Standard timer control element )
1
For manual and time-controlled switching of blinds and Automatic switchover from summer time to winter time
roller blinds. (switch-off function).
With dusk to dawn program including (Astro-program) Switching times/programme are safely stored in the
Individual Astro adjustment and Astro blocking time. event of a mains power failure.
The controlled devices can be manually operated at any Power reserve for time and date > 10 years.
time. Simple toggling between manual/automatic/vacation
Simple setting via high-resolution display with modes.
background illumination. Combined with Busch-Blind control II insert
With preset switching times/date/time. 6411 U/S-101, sun protection and twilight function.
Factory-set switching times can be individually Freely adjustable temperature and brightness-
adjusted. dependent sun protection function.
Automatic switchover from summer time to winter time Freely adjustable twilight function.
(switch-off function). User-adjustable running times for blinds and air 11
Switching times/programme are safely stored in the conditioning.
event of a mains power failure. Programming possible only with control element
Power reserve for time and date > 10 years. attached and energized.
Simple toggling between manual/automatic/vacation 6 switching times per day can be user-defined for each
modes. day of the week.
Programming possible only with control element Astro switching times and switching times can be
attached and energized. combined.
2 switching times per day can be user-defined for each When combined with LED dimmer 6524 U, Busch-
day of the week. Universal master dimmer insert 6593 U or Busch-
Astro switching times and switching times can be Memory touch-type controller 6550 U-101, the
combined. brightness of the lighting can be adjusted for each ON
For basic blind insert 6418 U. switching time.
Temperature range (Device): 0 °C to 35 °C For Busch-Blind control II insert 6411 U-101,
6411 U/S-101.
6456-101 2CKA006410A0398 1/10 For Busch-Universal relay switch insert 6401 U-102.
For Busch-Universal master dimmer insert 6593 U.
1) See respective cover plates 6435-xx.
For LED dimmer insert 6524 U and 6526 U..
For Busch-Memory touch-type controller 6550 U-101.
Temperature range (Device): 0 °C to 35 °C
6455-101-500 2CKA006410A0399 1/10
1) See respective cover plates 6435-xx.
Time switch mechanism 16 A ) )
1
2
DP, break contact for staircases, exterior lighting, fans,
etc.
Running time: 15 min
For time-programmed switching of electrical
consumers.
Rated voltage: 230 V~, +10 % / -10 %
Rated current: 16 A, cos φ 0.25
Protection class (Device): IP 20
1070 U 2CKA001043A0025 1/10
1) For screw-fixing only
2) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
or 3060 wallbox concrete)
