11/104 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
pure stainless steel
Blind control / timers

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Busch-Blind control II switch insert ) Busch-Short-time timer insert ) 1
1
Suitable for blind, roller blind and awning drives with countdown timer
mechanical or electronic limit switch shut-off. For time-programmed switching of electrical
With two 230 V multi-way input terminals (Up/Down) for consumers. With control cover, without cover plate.
group control. Minimum timer time: 1 second.
With operating mode switch for the following modes: Maximum timer time: 9:59:59 hours.
normal, louvre, base station, position. Rated voltage: 230 V~, +10 % / -10 %
With party function (disables the local control unit) in Rated frequency: 50 Hz
combination with Busch-Blind control II control cover Outputs: 1x Normally open contact
6430-xx-xxx, 6066-xx-xxx. Rated current: 10 A, cos φ 1
Wind alarm, cleaning functions can be accommodated Rated power: 2300 VA
via extension input.
For control cover 6430-xx-xxx. Temperature range (Device): 0 °C to 35 °CIEC 60669-2-1,
For IR control element 6066-xx-xxx. British Standard EN 60669-2-1
For comfort timer control element 6455-101-500. 6465 U-101-500 2CKA006410A0393 1/10
Running time: 3 min
Rated voltage: 230 V~, +10 % / -10 % Mounting 35 mm deep flush 1gang
Rated frequency: 50 Hz boxes: or Dual Box 3070-2/35 BSDB.
Outputs: 2x Normally open contact Cover frames: 1gang frame 1721 BS-2xG
Rated current: 3 A, cos φ 0.5 or Dual Box frame 1722 BSDB-2xG.
Rated power: 690 VA
2gang product 2gang combination with adapter plate
combinations: APBS in Dual Box only.
Control/Signal outputs: 2
Temperature range (Device): 0 °C to 35 °C neon indicator: not applicable
6411 U-500-101 2CKA006410A0378 1/10 1) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
1) Compatible with types 6411 U/x.
or 3060 wallbox concrete)
11
Brightness sensor Rocker
For insert 6411U/S-101. with marking
With 2 m connecting cable. As cover for flush-mounted blind control switch/push
Measuring range: 15-50,000 lux. switch. For inserts 2000/4 and 2020/4 US.
Material stainless steel.
Anti fingerprint.
Protection class (Device): IP 20
6414-101 2CKA006410A0389 1/10
stainless steel 1785 JA-866 2CKA001751A2964 10
Sun sensor
For insert 6411U/S-101. Cover plate
Measuring range: 5-50,000 lux. with rotary control, with marking
As cover for flush-mounted blind control switch/push
switch. For inserts 2712 U, 2713 U and 2722 U, 2723 U.
Material stainless steel.
Anti fingerprint.
6482 2CKA006410A0203 1 Protection class (Device): IP 20
stainless steel 1740-866 2CKA001710A3748 10

Cover plate )
1
with labelling field
With marking.
For half-cylindrical type switches and blind control
switch/push-switch. For inserts 2733 USL-101 and 2712
USL-101, 2713 USL-101, 2722 USL-101, 2723 USL-101.
Surface painted.
Protection class (Device): IP 20
stainless steel 1755 SL/PZ-866-101 2CKA001710A3749 10
1) For compatible lettering software, visit www.BUSCH-JAEGER-labelingtool.com.

Control element
For Busch-Blind control II insert 6411 U-101,
6411 U/S-101.
For basic blind insert 6418 U.
For Busch-Universal 2gang 1way insert 6402 U.
Surface painted.
stainless steel 6430-866-102 2CKA006430A0343 1/10
