pure stainless steel
Blind control / timers Socket outlets

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Time switch mechanism 16 A ) ) SCHUKO® socket outlet
1
2
DP, break contact for staircases, exterior lighting, fans, With screwless terminals.
etc. DP (2 P + E)
Running time: 120 min Material stainless steel.
For time-programmed switching of electrical Anti fingerprint.
consumers. Rated voltage: 250 V~
Rated voltage: 230 V~, +10 % / -10 % Rated current: 16 A
Rated current: 16 A, cos φ 0.25 Protection class (Device): IP 20
Protection class (Device): IP 20 stainless steel 20 EUC-866-500 2CKA002011A6212 10/100
1071 U 2CKA001043A0124 1
1) For screw-fixing only 1
2) Only in conjunction with standard flush-mounting boxes according to DIN 49073, SCHUKO® socket outlet )
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall shuttered
or 3060 wallbox concrete) With screwless terminals.
DP (2 P + E)
Material stainless steel.
Cover plate Anti fingerprint.
with rotary knob, with marking Rated voltage: 250 V~
For Busch-Timer insert 1070 U. Rated current: 16 A
Running time: 15 min Protection class (Device): IP 20
Surface painted.
Protection class (Device): IP 20 stainless steel 20 EUCKS-866-500 2CKA002013A5374 10/100
1) Increased shock protection .
stainless steel 1770-866-103 2CKA001753A0259 10
SCHUKO® USB socket outlet ) ) )
1
3
2
Cover plate shuttered
with rotary knob, with marking With screwless terminals.
11
For Busch-Timer insert 1071 U. DP (2 P + E)
Running time: 120 min For supply and support of mobile devices via USB-cable.
Surface painted. With USB female connector type A.
Protection class (Device): IP 20 With electronic short-circuit protection.
With electronic overload protection.
stainless steel 1771-866-103 2CKA001753A0302 10
Simultaneous charging via USB connection and use of
the SCHUKO® socket outlet.
Cover plate ) 1 Surface painted.
For comfort timer control element 6455-101-500. Rated voltage: 250 V~
For standard timer control element 6456-101. Secondary: 5 V-, +5 % / -5 %
For room thermostats 1098 U-101 and 1098 UF-101. Rated frequency: 50 Hz
For short-time timer 6465 U-101. Suitable for: SCHUKO® socket outlet
For Busch-CO2 sensor 1091 U-500. Rated current: 16 A
Surface painted. Suitable for: USB connection
Rated current: 700 mA
stainless steel 6435-866 2CKA006430A0344 10 Protection class (Device): IP 20, SELV
1) Surface painted. Temperature range (Device): 5 °C to 35 °C
Dimensions: (L x W x D): 71 mm x 71 mm x 53 mm
Mounting depth: 35 mm
stainless steel 20 EUCBUSB-866-5002CKA002011A6184 1
1) Connecting terminals approved in accordance with VDE 0620-1 as connectors.
2) No data transfer.
3) Use dust cover 2098 when cleaning the device.
1
SCHUKO® socket outlet )
with labelling field
DP (2 P + E)
Size of labelling field: 60 x 9 mm.
Material stainless steel.
Anti fingerprint.
Rated voltage: 250 V~
Rated current: 16 A
Protection class (Device): IP 20
stainless steel 20 EUN-866 2CKA002011A3851 10
1) For compatible lettering software, visit www.BUSCH-JAEGER-labelingtool.com.
