solo®
Dimmers

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

1
Busch-touch dimmer ) ) ) Control element ) 1
3
2
flush mounted, 1-10V with neon lamp
3 wire connection (neutral conductor required). Combinable with Busch-Memory 2gang dimmer 6565 U.
For controlling ballast units for fluorescent lamps with
control output 1-10 V DC, control current max. 50 mA DC.
For control cover with control lamp 6543-xxx-10x.
For Busch-Remote control IR control cover 6066-xxx-10x
and 6067-xxx-10x. ivory white 6545-82 2CKA006599A2907 1/10
For comfort timer control element 6455-101-500. studio white 6545-84 2CKA006599A2908 1/10
For Busch-Watchdog 180 flush-mounted Sensor grey metallic ) 2 6545-803 2CKA006599A2943 1/10
Standard 6810-21x-101.
For Busch-Watchdog 180 flush-mounted sensor 1) Replacement neon lamp 3857.
Comfort II 6800-xxx-104 and 6800-xxx-104M. 2) Surface painted.
For Busch-Watchdog Presence tech 6813-xxx-101 und
6813/11-xxx. Cover plate
Combinable with Busch-Watchdog extension insert for cooling element
6805 U. For Busch-Universal master dimmer power module
Operation also possible via conventional push buttons 6594 U.
(2020 US, 2021/6 UK). For room temperature controller object range 6108/0x
For LED control via control gears and base for blind cover 6930/01.
Without control cover.
Rated voltage: 230 V~, +10 % / -10 % ivory white 6541-82 2CKA006599A2832 10
Rated frequency: 50 Hz studio white 6541-84 2CKA006599A2835 10
Rated power: 700 W/VA
IEC 60669-2-1, British Standard EN 60669-2-1 grey metallic ) 1 6541-803 2CKA006599A2940 10
1) Surface painted. 11
6550 U-101-500 2CKA006550A0042 1
1) Non-illuminable.
2) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
or 3060 wallbox concrete)
3) with integrated making-current limiter

Cover plate ) 1
with rotary knob, with indication lamp
Elevated knob.
With transparent luminous ring.
For Busch-Dimmer®.
For inserts
2112 U-101/2247 U/2250 U/6513 U-102/6517 U-10x/
6519 U/6520 U/6523 U(R)(10x) /6591 U-10x and 6592 U.
ivory white 6540-82-102 2CKA006599A2951 10/100
studio white 6540-84-102-500 2CKA006599A3009 10/100
grey metallic ) 6540-803-102 2CKA006599A2980 10
2
1) Replacement neon lamp, Art. No. 3855.
2) Surface painted.

Control element ) ) )
1
2
3
with neon lamp
Can be combined with LED dimmer 6524 U, and 6526 U,
Busch-Universal touch-type controller 6550 U-10x,
Busch-Memory touch dimmer 6560 U-101, Busch-
Universal-Dimmer® 6593 U, Busch-Universal relay insert
6401 U-10x, Busch-Universal 2gang insert 6402 U.
ivory white 6543-82-101 2CKA006599A2831 1/10
studio white 6543-84-101-500 2CKA006599A3010 1/10
4
grey metallic ) 6543-803-101 2CKA006599A2942 1/10
1) Compatible with previous type 6543-xxx.
2) Touch-type Controller 6550 U-xxx non-illuminable.
3) Replacement neon lamp 3857.
4) Surface painted.
