solo®
Movement detectors / comfort switches

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

1
2
Universal e-contact insert ) Busch-Comfort switch control element ) )
1
2-wire connection (neutral conductor not required) with neon lamp
For switching lighting systems. Movement detector/push-button switch combination.
For Busch-Comfort switch control element Push switch function possible at all times.
6815-...-101-500. For switching lighting systems that depend on
For Busch-Presence detector sensor 6813-…-102-500. brightness and movement.
Can be combined with Universal-Slave insert Extension of the detection range by means of master/
6440/05 U-500. slave combination.
Operation in 1gang 2way installations via push switch- Additional activation/deactivation possibility through
unit for combination with flush-mounted units. pushbutton input.
Operation also possible via conventional push buttons Adjustable operating mode: automatic mode, automatic
(motion-controlled) switch-on and switch-off.
(2020 US, 2021/6 UK). Adjustable operating mode: semiatuomatic, manual
2 supplementary inputs via 127 V push switch switch-on, automatic (time and motion-controlled)
(e.g. 2020 US), central disablement of all outputs switch-off.
possible, supplementary IR remote control is possible Adjustable operating mode: automatic switch-on,
via IR flying receiver 6045 E-101 manual switch-off.
Rated voltage: 230 V~, +10 % / -10 % With continuous light/continuous off function.
Rated frequency: 50 Hz - 60 Hz Adjustment elements on the rear.
Outputs: 1x Normally open contact, potential-bound Surveillance density: 9 sectors with 28 switching
Suitable for: 230 V~ LEDi segments.
Rated power: 2 - 80 W/VA Switch-off delay: 1 to 10 min., adjustable.
Suitable for: 230 V incandescent lamps/230 V halogen For Busch-Universal relay switch insert 6440/01 U-500.
lamps For Universal-e-contact insert 6440/04 U-500.
Rated power: 20 - 180 W For Universal-Slave insert 6440/05 U-500.
Suitable for: Low voltage halogen lamps operated by Control element: 2 controllers for setting the brightness
transformers. switching threshold and switch-off delay.
Rated power: 20 - 180 VA Display elements: LED for status display. 11
Temperature range (Device): -5 °C to 45 °C Detection range: frontal: 5 m, lateral: 3 m, Mounting
Dimensions: (L x W x D): 71 mm x 71 mm x 32 mm height: 1.1 m
Mounting depth: 31 mm Detection angle: 170 °
DIN EN 60669-2-1 Brightness limit value: 0.5 Lux - 500 Lux , Daytime
operation
Mounting height: 0.8 m - 1.2 m

Protection class (Sensor): IP 20
6440/04 U-500 2CKA006400A0088 1 Temperature range (Device): 0 °C to 35 °C
1) Only use dimmable high voltage LEDs. Dimensions: (L x W x D): 63 mm x 63 mm x 28.3 mm
DIN EN 60669-2-1
Universal-Slave insert ivory white 6815-82-101-500 2CKA006800A2830 1
3 wire connection (neutral conductor required). studio white 6815-84-101-500 2CKA006800A2834 1
For the extension of Busch-Comfort switch or Busch- 3 6815-803-101-500 2CKA006800A2836 1
Presence detector installations. grey metallic )
For communication with Universal relay insert 1) Please order the respective flush-mounted insert separately.
6440/01 U-500. 2) The range specifications refer to an ambient temperature of 21 °C.
3) Surface painted.
For communication with Universal-e-contact insert
6440/04 U-500.
For Busch-Comfort switch control element
6815-...-101-500.
For Busch-Presence detector sensor 6813-…-102-500.
Rated voltage: 230 V~, +10 % / -10 %
Rated frequency: 50 Hz - 60 Hz
Control/Signal outputs: 1, electronic output, potential-
bound
Temperature range (Device): -5 °C to 45 °C
Dimensions: (L x W x D): 71 mm x 71 mm x 32 mm
Mounting depth: 31 mm
6440/05 U-500 2CKA006400A0091 1
