11/286 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
basic55®
Dimmers Movement detectors / comfort switches

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Cover plate ) 1 Busch-Universal relay switch insert
with rotary knob, with indication lamp 3 wire connection (neutral conductor required).
For Busch-Dimmer®. For Busch-Watchdog 180 flush-mounted Sensor
For inserts Standard 6810-21x-101. For Busch-Watchdog 180
2112 U-101/2247 U/2250 U/6513 U-102/6517 U-10x/ flush-mounted sensor Comfort II 6800-xxx-104 and
6519 U/6520 U/6523 U(R)(10x) /6591 U-10x and 6592 U. 6800-xxx-104M. For Busch-Watchdog 180 FP sensor for
All Weather 44 6800-3x-102C.
white 2115-92-507 2CKA006599A2929 10 For Busch-Watchdog Presence tech 6813-xxx-101 und
champagne 2115-93-507 2CKA006599A2990 10 6813/11-xxx.
For comfort timer control element 6455-101-500.
alpine white 2115-94-507 2CKA006599A2928 10
For Busch-Remote control IR control cover 6067-xxx-10x.
château-black 2115-95-507 2CKA006599A2991 10 For control cover with control lamp 6543-xxx-10x.
chalet-white 2115-96-507 2CKA006599A2992 10 Combinable with Busch-Watchdog extension insert
6805 U.
1) Replacement neon lamp, Art. No. 3855.
Operation also possible via conventional push buttons
(2020 US, 2021/6 UK).
3
1
2
Control element ) ) ) Rated voltage: 230 V~, +10 % / -10 %
with neon lamp Rated frequency: 50 Hz
Can be combined with LED dimmer 6524 U, and 6526 U, Outputs: 1x Normally open contact, potential-bound
Busch-Universal touch-type controller 6550 U-10x, Suitable for: 230 V incandescent lamps, 230 V halogen
Busch-Memory touch dimmer 6560 U-101, Busch- lamps, fluorescent lamps and low-voltage halogen
Universal-Dimmer® 6593 U, Busch-Universal relay insert lamps, that are operated via transformers.
6401 U-10x, Busch-Universal 2gang insert 6402 U. Rated current: 10 AX
Rated power: 2300 W/VA
white 6543-92-507 2CKA006599A2996 1/10
champagne 6543-93-507 2CKA006599A2993 1/10 Temperature range (Device): -25 °C to 55 °C60669-2-1
alpine white 6543-94-507 2CKA006599A2997 1/10
11
château-black 6543-95-507 2CKA006599A2994 1/10 6401 U-102-500 2CKA006401A0049 1/10
chalet-white 6543-96-507 2CKA006599A2995 1/10
1) Compatible with previous type 6543-xxx. Busch-Universal 2gang 1way insert
2) Touch-type Controller 6550 U-xxx non-illuminable. 3 wire connection (neutral conductor required).
3) Replacement neon lamp 3857.
For the serial switch operating mode: 2 separate
outputs, 2 separate extension inputs. For operation
mode timer: output 1 (eg lighting), output 2: ON/Off
delay in dependence of output 1 (eg fan control).
For Busch-Watchdog 180 flush-mounted Sensor
Standard 6810-21x-101. For Busch-Watchdog 180 flush-
mounted sensor Comfort II 6800-xxx-104 and 6800-xxx-
104M. For Busch-Watchdog Presence tech 6813-xxx-101
und 6813/11-xxx.
For Busch-Remote control IR control cover 6066-xxx-10x
and 6067-xxx-10x.
For control cover 6430-xxx-10x and 6543-xxx-10x.
Combinable with Busch-Watchdog extension insert
6805 U.
Operation also possible via conventional push buttons
(2020 US, 2021/6 UK).
Rated voltage: 230 V~, +10 % / -10 %
Rated frequency: 50 Hz
Outputs: 2x Normally open contact, potential-bound
Suitable for: 230 V incandescent lamps, 230 V halogen
lamps, fluorescent lamps and low-voltage halogen
lamps, that are operated via transformers.
Rated current: 10 AX
Rated power: 2300 W/VA
Temperature range (Device): 0 °C to 35 °CBritish
Standard EN 60669-2-1

6402 U-500 2CKA006401A0051 1/10
Mounting 35 mm deep flush 1gang
boxes: or Dual Box 3070-2/35 BSDB.
2gang product 2gang combination with adapter plate
combinations: APBS in Dual Box only.
neon indicator: neon lamp 3855, one neon lamp is supplied together with
control cover plates 6540-2x.
