11/284 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
basic55®
Dimmers

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

2
Busch-rotary dimmer ) Busch-touch dimmer ) )
1
1
flush mounted, DALI flush mounted, RL, 25-500 W
For DALI broadcast service (via central telegram). With light-level memory and leading edge control.
For switching and dimming up to 64 DALI- devices For incandescent lamps, 230 V tungsten halogen
like electronic ballasts and transformers with DALI- lamps and low-volt halogen lamps with conventional
interface. transformer.
With rotary control and ON/OFF push operation. Compatible with control covers 6543-xxx-10x.
Fool proved. Operation also possible via conventional push buttons
Brightness power-on level and backround brightness (2020 US, 2021/6 UK).
level adjustable, buffered. Parallel operation of several transformers and/or
With integrated LED illumination for orientation. incandescents lamps possible.
Color of orientation light adjustable (18 presets and Without control cover.
OFF). Rated voltage: 230 V~, +10 % / -10 %
Up to 5 potentiometers are connectable in parallel. Rated frequency: 50 Hz - 60 Hz
Max. current consumption: 15 mA. Rated power: 25 - 500 W/VA
Not suitable for combining with other DALI sensors or IEC 60669-2-1, British Standard EN 60669-2-1
central units of other manufacturers.
An additional DALI power supply is needed, e.g. by
Tridonic, Philips, Helvar or 2117/11 U. 6560 U-101-500 2CKA006560A1207 1/10
Max. DALI-cable length: 300 m (1,5 - 2,5 mm²). 1) In the case of conventional transformers, take ~20% transformer loss into account.
Without cover plate. 2) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
Protection class (Device): IP 20 Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
Temperature range (Device): 0 °C to 35 °C or 3060 wallbox concrete)
2117 U-500 2CKA006599A2987 1
1) Only in conjunction with standard flush-mounting boxes according to DIN 49073, Busch-rotary dimmer ) ) ) )
3
4
1
2
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall flush mounted, R, 60-600 W
11
or 3060 wallbox concrete)
With rotary control, 2way On-Off switching and
soft-catch.
Busch-rotary dimmer ) Leading Edge control.
1
flush mounted, DALI, with internal power supply For incandescent lamps and 230 V tungsten halogen
For DALI broadcast service (via central telegram). lamps.
With integrated DALI power adaptor. With adjustable minimum brightness.
For switching and dimming up to 64 DALI- devices Without cover plate.
like electronic ballasts and transformers with DALI- Rated voltage: 230 V~, +10 % / -10 %
interface. Rated frequency: 50 Hz
With rotary control and ON/OFF push operation. Rated power: 60 - 600 W
With electronic short-circuit protection. IEC 60669-2-1, British Standard EN 60669-2-1
With electronic overload protection.
Brightness power-on level and backround brightness
level adjustable, buffered. 2250 U-507 2CKA006515A0840 1/10
With integrated LED illumination for orientation. 1) Illuminable with neon lamp. Neon lamp included in delivery with cover plate.
Color of orientation light adjustable (18 presets and 2) Also applicable for 1gang 2way installations.
OFF). 3) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
Up to 5 potentiometers are connectable in parallel. Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
Up to 3 potentiometers are connectable in parallel in or 3060 wallbox concrete)
active mode. 4) Provided with terminal for net disconnection devices.
Not suitable for combining with other DALI sensors or
central units of other manufacturers. 1 2
DALI-voltage: 15,5 V= Dimmer ) )
Rated current: max. 75 mA with leading edge control
Power consumption: < 2,5 W For incandescent lamps and 230 V tungsten halogen
Number of DALI-units: lamps.
37 in case of one active power-potentiometer Rated voltage: 230 V~, +10 % / -10 %
in case of three active power-potentiometer in parallel Rated frequency: 50 Hz
connection: 111 Rated power: 60 - 400 W
Active mode: the potentiometer is supporting the IEC 60669-2-1, British Standard EN 60669-2-1
necessary control circuit for other DALI-devices.
Passive mode: the potentiometer is suitable as
additional operation point. white 2200 U-500 2CKA006514A0112 1/10
Max. DALI-cable length: 300 m (1,5 - 2,5 mm²). 1) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
Without cover plate. Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
Rated voltage: 230 V~, +10 % / -10 % or 3060 wallbox concrete)
Rated frequency: 50 Hz - 60 Hz 2) Non-illuminable.
Protection class (Device): IP 20
Temperature range (Device): 0 °C to 35 °C
2117/11 U-500 2CKA006599A2988 1
1) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
or 3060 wallbox concrete)
