11/288 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
basic55®
Movement detectors / comfort switches

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Busch-Watchdog 180 flush-mounted comfort Busch-Universal relay switch insert
sensor II ) 3 wire connection (neutral conductor required).
1
with select-lens For switching lighting systems. For Busch-Comfort
For automatic switching of devices dependent on switch control element 6815-...-101-500. For Busch-
motion and brightness. For relay inserts 6401 U-102, Presence detector sensor 6813-…-102-500.
6402 U and 6812 U-101. For MOS-Fet insert 6804 U-101. Can be combined with Universal-Slave insert
For Dimmer insert 6593 U. For extension insert 6805 U. 6440/05 U-500.
With integrated selector switch for ON-AUTOMATIC-OFF Operation in 1gang 2way installations via push switch-
(lockable). unit for combination with flush-mounted units.
Soft phase-out: In combination with the 6593 U (mode Operation also possible via conventional push buttons
of operation: Soft OFF) the illumination is dimmed (2020 US, 2021/6 UK).
down within 60 sec and switched off. 2 supplementary inputs via 127 V push switch
Surveillance density: 18 sectors with 72 switching (e.g. 2020 US), central disablement of all outputs
segments. possible, supplementary IR remote control is possible
Switch-off delay: 10 sec to 30 min or short-time pulse via IR flying receiver 6045 E-101
1 sec adjustable. Rated voltage: 230 V~, +10 % / -10 %
Detection range: frontal: 12 m, lateral: 8 m Rated frequency: 50 Hz - 60 Hz
Detection angle: 180 ° Outputs: 1x Normally open contact, potential-bound
Brightness limit value: 5 Lux Up to daytime operation Suitable for: 230 V~ LEDi
Mounting height: 0.8 m - 1.2 m Rated power: 100 W/VA
Protection class (Sensor): IP 20 Suitable for: 230 V incandescent lamps/230 V halogen
Temperature range (Device): 0 °C to 35 °C lamps
Rated current: 10 AX
white 6800-92-104-507 2CKA006800A2635 1
Rated power: 2300 W
champagne 6800-93-104-507 2CKA006800A2637 1 Suitable for: Low voltage halogen lamps operated by
alpine white 6800-94-104-507 2CKA006800A2636 1 transformers.
Rated power: 2300 VA
11
château-black 6800-95-104-507 2CKA006800A2638 1
Temperature range (Device): -5 °C to 45 °C
chalet-white 6800-96-104-507 2CKA006800A2639 1 Dimensions: (L x W x D): 71 mm x 71 mm x 32 mm
1) Please order the respective flush-mounted insert separately. Mounting depth: 31 mm
DIN EN 60669-2-1
Busch-Watchdog 180 flush-mounted comfort LEDi
sensor II ) ) 6440/01 U-500 2CKA006400A0085 1
2
1
with multi-lens
For automatic switching of devices dependent on
motion and brightness. For down-to-ground detection. Universal e-contact insert ) 1
For relay inserts 6401 U-102, 6402 U and 6812 U-101. 2-wire connection (neutral conductor not required)
For MOS-Fet insert 6804 U-101. For Dimmer insert For switching lighting systems. For Busch-Comfort
6593 U. For extension insert 6805 U. switch control element 6815-...-101-500.
With integrated selector switch for ON-AUTOMATIC-OFF For Busch-Presence detector sensor 6813-…-102-500.
(lockable). Can be combined with Universal-Slave insert
Soft phase-out: In combination with the 6593 U (mode 6440/05 U-500.
of operation: Soft OFF) the illumination is dimmed Operation in 1gang 2way installations via push switch-
down within 60 sec and switched off. unit for combination with flush-mounted units.
Surveillance density: 28 sectors with 112 switching Operation also possible via conventional push buttons
segments. (2020 US, 2021/6 UK).
Switch-off delay: 10 sec to 30 min or short-time pulse 2 supplementary inputs via 127 V push switch
1 sec adjustable. (e.g. 2020 US), central disablement of all outputs
Detection range: frontal: 15 m, lateral: 5 m, Mounting possible, supplementary IR remote control is possible
height: 2.5 m via IR flying receiver 6045 E-101
Detection range 2: frontal: 10 m, lateral: 2.5 m, Mounting Rated voltage: 230 V~, +10 % / -10 %
height: 1.2 m Rated frequency: 50 Hz - 60 Hz
Detection angle: 180 ° Outputs: 1x Normally open contact, potential-bound
Brightness limit value: 5 Lux Up to daytime operation Suitable for: 230 V~ LEDi
Mounting height: 0.8 m - 1.2 m alternative: 2.5 m Rated power: 2 - 80 W/VA
Protection class (Sensor): IP 20 Suitable for: 230 V incandescent lamps/230 V halogen
Temperature range (Device): 0 °C to 35 °C lamps
Rated power: 20 - 180 W
white 6800-92-104M-507 2CKA006800A2640 1 Suitable for: Low voltage halogen lamps operated by
champagne 6800-93-104M-507 2CKA006800A2642 1 transformers.
alpine white 6800-94-104M-507 2CKA006800A2641 1 Rated power: 20 - 180 VA
Temperature range (Device): -5 °C to 45 °C
château-black 6800-95-104M-507 2CKA006800A2643 1 Dimensions: (L x W x D): 71 mm x 71 mm x 32 mm
chalet-white 6800-96-104M-507 2CKA006800A2644 1 Mounting depth: 31 mm
DIN EN 60669-2-1
1) installation: slide switch top.
2) Please order the respective flush-mounted insert separately.

6440/04 U-500 2CKA006400A0088 1
1) Only use dimmable high voltage LEDs.
