basic55®
Movement detectors / comfort switches

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Busch-Watchdog relay mechanism Busch-Watchdog extension insert ) 1
3 wire connection (neutral conductor required). 3 wire connection (neutral conductor required).
For Busch-Watchdog 180 flush-mounted Sensor For extending Busch-Watchdog 180 flush-mounted and
Standard 6810-21x-101. Busch-Watchdog Presence tech installations.
For Busch-Watchdog 180 flush-mounted sensor For combination with relay insert 6401 U-102 and
Comfort II 6800-xxx-104 and 6800-xxx-104M. 6402 U.
For Busch-Watchdog Presence tech 6813-xxx-101 und For combination with MOS-Fet insert 6804 U-101.
6813/11-xxx. For combination with Dimmer insert 6593 U and
Rated voltage: 230 V, +10 % / -10 % 6550 U-101.
Rated frequency: 50 Hz For Busch-Watchdog 180 flush-mounted sensor
Outputs: 1x Normally open contact, potential-bound Comfort II 6800-xxx-104 and 6800-xxx-104M.
Suitable for: 230 V incandescent lamps, 230 V halogen For Busch-Watchdog Presence tech 6813-xxx-101 und
lamps, fluorescent lamps and low-voltage halogen 6813/11-xxx.
lamps, that are operated via transformers. Rated voltage: 230 V~, +10 % / -10 %
Rated power: 700 W/VA Rated frequency: 50 Hz
Control/Signal outputs: 1, electronic output, potential-
Temperature range (Device): 0 °C to 55 °CBritish bound
Standard EN 60669-2-1 Temperature range (Device): 0 °C to 35 °C
6805 U-500 2CKA006800A2161 1/10
6812 U-101-500 2CKA006800A2160 1/10 Mounting 35 mm deep flush 1gang
boxes: or Dual Box 3070-2/35 BSDB.
4
1
2
Busch-Watchdog MOS-Fet Insert ) ) ) ) ) ) Cover frames: 1gang frame 1721 BS-2xG
6
5
3
2-wire connection (neutral conductor not required) or Dual Box frame 1722 BSDB-2xG.
For Busch-Watchdog 180 flush-mounted Sensor 2gang product 2gang combination with adapter plate
Standard 6810-21x-101. combinations: APBS in Dual Box only. 11
For Busch-Watchdog 180 flush-mounted sensor
1) Not combinable with relay switch insert 6812 U-101.
Comfort II 6800-xxx-104 and 6800-xxx-104M.
For Busch-Watchdog Presence tech 6813-xxx-101 und
6813/11-xxx. Busch-Watchdog 180 flush-mounted standard sensor )
1
Combinable with Busch-Watchdog extension insert with select-lens
6805 U. For automatic switching of devices dependent on
Operation also possible via conventional push buttons motion and brightness.
(2020 US, 2021/6 UK). For relay inserts 6401 U-102, 6402 U and 6812 U-101.
Rated voltage: 230 V~, +10 % / -10 % For MOS-Fet insert 6804 U-101.
Rated frequency: 50 Hz For Dimmer insert 6593 U.
Suitable for: 230 V incandescent lamps, 230 V halogen Surveillance density: 18 sectors with 72 switching
lamps and low-voltage halogen lamps with conventional segments.
transformers or Busch Electronic Transformer. Switch-off delay: 80 sec.
Rated power: 60 - 420 W/VA Detection range: frontal: 12 m, lateral: 8 m
Detection angle: 180 °
Temperature range (Device): 0 °C to 35 °CBritish Brightness limit value: 5 Lux Up to daytime operation
Standard EN 60669-2-1 Mounting height: 0.8 m - 1.2 m
Protection class (Sensor): IP 20
Temperature range (Device): 0 °C to 35 °C
6804 U-101-500 2CKA006800A2219 1/10
white 6810-92-101-507 2CKA006810A0004 1/10
1) In case of electronic transformers, 5 % transformer losses.
2) In the case of conventional transformers, take ~20% transformer loss into account. champagne 6810-93-101-507 2CKA006810A0006 1
3) Not suitable for the activation of energy-saving lamps, conventional and electronic
ballast units and LED lamps. alpine white 6810-94-101-507 2CKA006810A0005 1
4) Not suitable for activating the staircase time delay. château-black 6810-95-101-507 2CKA006810A0007 1
5) Cannot be used to control relais.
6) Requires an NIS international socket, E-No. 372507676. chalet-white 6810-96-101-507 2CKA006810A0008 1
1) Please order the respective flush-mounted insert separately.
