basic55®
Movement detectors / comfort switches Blind control / timers

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Universal-Slave insert Blind switch with cover )
1
3 wire connection (neutral conductor required). SP, switch
For the extension of Busch-Comfort switch or Busch- With interlock.
Presence detector installations. Rated voltage: 250 V~
For communication with Universal relay insert Rated current: 10 AXIEC60669-1
6440/01 U-500.
For communication with Universal-e-contact insert
6440/04 U-500. white 2006/4 UC-92-507 2CKA001012A2147 10
For Busch-Comfort switch control element champagne 2006/4 UC-93-507 2CKA001012A2166 10
6815-...-101-500. alpine white 2006/4 UC-94-507 2CKA001012A2140 10
For Busch-Presence detector sensor 6813-…-102-500.
Rated voltage: 230 V~, +10 % / -10 % château-black 2006/4 UC-95-507 2CKA001012A2176 10
Rated frequency: 50 Hz - 60 Hz chalet-white 2006/4 UC-96-507 2CKA001012A2186 10
Control/Signal outputs: 1, electronic output, potential- 1) These blind switches/push buttons safely prevent a switch-over of the running
bound direction being carried out too quickly.
Temperature range (Device): -5 °C to 45 °C
Dimensions: (L x W x D): 71 mm x 71 mm x 32 mm
Mounting depth: 31 mm Blind switch with cover )
1
6440/05 U-500 2CKA006400A0091 1 SP, push switch.
With interlock.
Rated voltage: 250 V~
Busch-Comfort switch control element ) ) Rated current: 10 AIEC60669-1
1
2
with neon lamp
Movement detector/push-button switch combination.
Push switch function possible at all times. white 2026/4 UC-92-507 2CKA001413A1085 10
For switching lighting systems that depend on champagne 2026/4 UC-93-507 2CKA001413A1094 10
brightness and movement. 11
Extension of the detection range by means of master/ alpine white 2026/4 UC-94-507 2CKA001413A1082 10
slave combination. château-black 2026/4 UC-95-507 2CKA001413A1098 10
Additional activation/deactivation possibility through chalet-white 2026/4 UC-96-507 2CKA001413A1102 10
pushbutton input.
Adjustable operating mode: automatic mode, automatic 1) These blind switches/push buttons safely prevent a switch-over of the running
(motion-controlled) switch-on and switch-off. direction being carried out too quickly.
Adjustable operating mode: semiatuomatic, manual
switch-on, automatic (time and motion-controlled) Blind switch with cover ) )
1
2
switch-off. SP, N, E
Adjustable operating mode: automatic switch-on, With rotary knob/switch and push switch.
manual switch-off. Rated voltage: 250 V~
With continuous light/continuous off function. Rated current: 10 AXIEC 60669-1
Adjustment elements on the rear.
Surveillance density: 9 sectors with 28 switching
segments. white 2713 UCDR-92-507 2CKA001101A0922 10
Switch-off delay: 1 to 10 min., adjustable. champagne 2713 UCDR-93-507 2CKA001101A0926 10
For Busch-Universal relay switch insert 6440/01 U-500.
For Universal-e-contact insert 6440/04 U-500. alpine white 2713 UCDR-94-507 2CKA001101A0920 10
For Universal-Slave insert 6440/05 U-500. château-black 2713 UCDR-95-507 2CKA001101A0928 10
Control element: 2 controllers for setting the brightness
switching threshold and switch-off delay. chalet-white 2713 UCDR-96-507 2CKA001101A0930 10
Display elements: LED for status display. 1) Blind switches/push switches prevents fast change over between operating
Detection range: frontal: 5 m, lateral: 3 m, Mounting directions.
2) Also suitable for DC drives.
height: 1.1 m
Detection angle: 170 °
Brightness limit value: 0.5 Lux - 500 Lux , Daytime Blind switch with cover ) )
2
1
operation SP, N, E
Mounting height: 0.8 m - 1.2 m With rotary knob/push button.
Protection class (Sensor): IP 20 Rated voltage: 250 V~
Temperature range (Device): 0 °C to 35 °C Rated current: 10 AIEC60669-1
Dimensions: (L x W x D): 55.5 mm x 55.5 mm x 28.3 mm
DIN EN 60669-2-1
white 2723 UCDR-92-507 2CKA001101A0923 10
white 6815-92-101-507 2CKA006800A2848 1
champagne 2723 UCDR-93-507 2CKA001101A0927 10
3
champagne ) 6815-93-101-507 2CKA006800A2849 1
alpine white 2723 UCDR-94-507 2CKA001101A0921 10
alpine white 6815-94-101-507 2CKA006800A2850 1
château-black 2723 UCDR-95-507 2CKA001101A0929 10
château-black 6815-95-101-507 2CKA006800A2851 1
chalet-white 2723 UCDR-96-507 2CKA001101A0931 10
chalet-white 6815-96-101-507 2CKA006800A2852 1
1) Blind switches/push switches prevents fast change over between operating
1) Please order the respective flush-mounted insert separately.
directions.
2) The range specifications refer to an ambient temperature of 21 °C.
2) Also suitable for DC drives.
3) Surface painted.
