basic55®
Data communication

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Data-connection box, RJ 45, cat. 6a iso, shielded ) Stereo loudspeaker connection box )
1
1
2 x outlets, 8/8-pole With screwless terminals (with screw-type terminals on
With down-leading outlet and LSA self-cutting clamps. the back).
RJ-45 terminals for networks according to Cat 6A, Class With 4 terminals.
EA (10 Gbits/s / 500MHz). Cable cross-section max. 10 mm2.
Equates to cat. 6a, Class EA according to Polarity is indicated by color.
ISO/IEC 11801:2011-06. With claw.
Terminal marking A and B according to TIA/EIA-568-B.2. Protection class (Device): IP 20
Typ according to EN 60 603-7-51:2011-01. white 0248/02-101 2CKA000230A0402 10/100
Shielding according to DIN EN 55022, Class B.
Up to 500 MHz on all pairs of wires. 1) Suitable for cover telephone unit 1766-xxx and 2539-21x.
Suitable for 10-Gigabit Ethernet.
Suitable for PoE+ according to IEEE 802.3at, >- 1.000 Stereo loudspeaker connection box )
1
contact durability. With screwless terminals (with screw-type terminals on
Flex cable entries from all sides without buckles. the back).
Earthing of housing via 6,3 mm blade terminal at the With 4 terminals.
back possible. Cable cross-section max. 10 mm2.
Re-embedded proofed. Polarity is indicated by color.
Suitable for Mix-and-Match operation. With claw.
Suitable for RJ 11, RJ 12 und RJ 45. Protection class (Device): IP 20
For data cables with a diameter of 6 -10 mm.
For trunk systems, flush-mounted wall boxes and alpine white 0248/04-101-500 2CKA000230A0464 10/100
underfloor systems. 1) Suitable for cover telephone unit 1766-xxx and 2539-21x.
For wires of AWG 24-22.
Without claws.
1
Mounting depth: 31 mm. Stereo loudspeaker connection box )
Protection class (Device): IP 20 With screwless terminals (with screw-type terminals on 11
the back).
metal clad 0218/12-101-507 2CKA000230A0412 1/10 With 4 terminals.
1) Suitable for cover plate 1803-02-xxx. Cable cross-section max. 10 mm2.
Polarity is indicated by color.
With claw.
Universal data connection unit, RJ45, Cat. 6e, Protection class (Device): IP 20
unshielded, with down-leading outlet ) 1
2 x outlets, 8/8-pole anthracite 0248/05-101 2CKA000230A0404 10/100
With down-leading outlet and LSA self-cutting clamps. 1) Suitable for cover telephone unit 1766-xxx and 2539-21x.
Cat. 6 according to DIN EN 50173-1:2003-06, ISO/IEC
1180:2002, and TIA/EIA-568-B.2:2002.
Cat. 6a (Category 6 augmented ) in accordance with USB connection unit ) 1
TIA/EIA-TR 42.7. with screw-type terminals and strain relief
Marking in accordance with EIA/TIA 568 A and B. Suitable for telephone connection unit cover plates
Design according to IEC 60 603-7-2:2007. 2539-21x and 1766-xxx.
Up to 250 MHz on all pairs of wires. To link mobile devices like e.g. printer, scanner, USB-
Suitable for 10-Gigabit Ethernet. sticks or digital cameras etc.
With claw. USB-type A, USB 2.0 compatible.
For 5-wire USB- cables via srew-type terminals.
0221/12-507 2CKA000230A0400 10
For trunk systems, flush-mounted wall boxes and
1) Suitable for cover plate 1803-02-xxx. underfloor systems.
For easy installation and to follow the valid bending
radii the "Kaiser- electronic-wall-box" type 1068-02 or
Flush-mounted assembly adapter 9062-74 is recommended.
For the accommodation of one or two universal Without cover plate.
modules 0219. Without claws.
For flush-mounted installation. Protection class (Device): IP 20
Suitable for telephone connection unit cover plates Mounting depth: 34 mm
2539-21x and 1766-xxx.
Protection class (Device): IP 20 white 0261/11-500 2CKA000230A0418 1
0219/12 2CKA000230A0395 1/10 1) Please follow the recommendations of the cable and device producers for the max.
USB cable lengths.
Channel assembly adapter
For the accommodation of one or two universal
modules 0219.
For channel and under-floor installation.
Suitable for telephone connection unit cover plates
2539-21x and 1766-xxx.
Protection class (Device): IP 20
0219/13 2CKA000230A0396 1/10
