basic55®
Data communication

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

1
VGA connection unit ) Antenna socket insert Radio/TV
with screw-type terminals and strain relief 2 connectors/loop through type
Suitable for telephone connection unit cover plates Broadband technology 5-2.400 MHz
2539-21x and 1766-xxx. To link analogue video data For DVB-T, satellite and broad-band cable systems.
between PCs and laptops to monitors or digital For analogue and digital transmission.
projectors etc. VGA-type: D-type, 15-pole. With claw.
Fully HD ready (1920 x 1080 pixel). Minimal installation depth, class A.
For 15-wire VGA-cables via srew-type terminals. Protection class (Device): IP 20
For trunk systems, flush-mounted wall boxes and 0231-101 2CKA000230A0268 10/100
underfloor systems.
For easy installation and to follow the valid bending
radii the "Kaiser- electronic-wall-box" type 1068-02 or Satellite co-axial outlets Radio/TV/SAT
9062-74 is recommended. 3gang dead-end feeder
Without cover plate. Without claws. Broadband technology 47-2.150 MHz.
Protection class (Device): IP 20 SAT connection designed as screwable F-male plug.
Mounting depth: 34 mm with remote feed via F-bush
white 0261/21-500 2CKA000230A0424 1 For DVB-T and broadband-cable-systems.
For analogue and digital transmission.
1) Please follow the recommendations of the cable and device producers for the max.
VGA cable lengths. With claw.
Minimal installation depth, class A.
Protection class (Device): IP 20
HDMI connection unit ) 0232-101-500 2CKA000230A0463 10/100
1
with screw-type terminals and strain relief
Suitable for telephone connection unit cover plates
2539-21x and 1766-xxx. Terminating resistor
To link high-definition digital audio and video data from 75 Ohm
e.g. SAT-receiver, DVD-/Blue-Ray-player to plasma-type, Protection class (Device): IP 20
11
LCD- or-LED-TVs/screens.
HDMI-type A, 3D-compatible.
Fully HD ready (1920 x 1080 pixel).
For 20-wire HDMI-cables via srew-type terminals.
For trunk systems, flush-mounted wall boxes and 0239 2CKA000230A0201 10/100
underfloor systems.
For easy installation and to follow the valid bending
radii the "Kaiser- electronic-wall-box" type 1068-02 or Modular-Jack insert
9062-74 is recommended. Cat. 5e non-shielded, 8 (8)-pole
Without cover plate. Without claws. For cover plate 2561-xxx, 2561-02-xxx and insert 1812,
Protection class (Device): IP 20 1866 built-in, 1867 built-in.
Mounting depth: 34 mm For conductor cross-sections of 0.12 mm² (AWG 26) to
0.35 mm² (AWG 22).
white 0261/31-500 2CKA000230A0430 1
0211/11-507 2CKA000225A0153 1/10
1) Please follow the recommendations of the cable and device producers for the max.
HDMI cable lengths.
Modular-Jack insert
TV outlet 6-pole Cat. 3 (AMP-No. 216000-2)
For connection to a TV or FM co-axial aerial lead. For cover plate 2561-xxx, 2561-02-xxx and insert 1812,
Rated frequency: 5000 Hz - 860000 HzIEC 60169-2 1866 built-in, 1867 built-in.
For conductor cross-sections of 0.12 mm² (AWG 26) to
0.35 mm² (AWG 22).
Protection class (Device): IP 20
0210 2CKA000225A0078 10
white 1743-01-92-507 2CKA001724A4280 10/100
champagne 1743-01-93-507 2CKA001724A4310 10/100
Modular-Jack insert
alpine white 1743-01-94-507 2CKA001724A4276 10/100 8-pole Cat. 3 (AMP-No. 216005-4)
château-black 1743-01-95-507 2CKA001724A4313 10 For cover plate 2561-xxx, 2561-02-xxx and insert 1812,
1866 built-in, 1867 built-in.
chalet-white 1743-01-96-507 2CKA001724A4317 10
For conductor cross-sections of 0.12 mm² (AWG 26) to
0.35 mm² (AWG 22).
Satellite co-axial outlets Protection class (Device): IP 20
2 connectors/dead-end feeder 0211 2CKA000225A0086 10
Broadband technology 5-2.400 MHz
For DVB-T, satellite and broad-band cable systems.
For analogue and digital transmission.
With claw.
Minimal installation depth, class A.
Protection class (Device): IP 20
0230-101-507 2CKA000230A0380 10/100
