11/292 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
basic55®
Socket outlets

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

SCHUKO® socket outlet Cover plate
with hinged lid shuttered
With screwless terminals. For socket outlet insert 20 M-500.
DP (2 P + E)
Hinged lid notches when opened.
Rated voltage: 250 V~
Rated current: 16 A
white 2399 UCKS-92-507 2CKA002099A0251 10
white 20 EUK-92-507 2CKA002018A0351 10/100
champagne 2399 UCKS-93-507 2CKA002099A0259 10
champagne 20 EUK-93-507 2CKA002018A1498 10
alpine white 2399 UCKS-94-507 2CKA002099A0250 10
alpine white 20 EUK-94-507 2CKA002018A0350 10/100
château-black 2399 UCKS-95-507 2CKA002099A0260 10
château-black 20 EUK-95-507 2CKA002018A1499 10
chalet-white 2399 UCKS-96-507 2CKA002099A0261 10
chalet-white 20 EUK-96-507 2CKA002018A1500 10
Double SCHUKO® socket outlets
SCHUKO® socket outlet With screwless terminals.
with hinged lid DP (2 P + E)
Shuttered. Suitable for 1gang flush-mounted boxes.
With screwless terminals. Rated voltage: 250 V~
DP (2 P + E) Rated current: 16 A
Hinged lid notches when opened.
Rated voltage: 250 V~ white 20-02 EUJ-92-507 2CKA002014A1463 10/80
Rated current: 16 A champagne 20-02 EUJ-93-507 2CKA002014A1476 10
white 20 EUKB-92-507 2CKA002111A0652 10 alpine white 20-02 EUJ-94-507 2CKA002014A1462 10/80
champagne 20 EUKB-93-507 2CKA002111A0653 10 château-black 20-02 EUJ-95-507 2CKA002014A1477 10
11
alpine white 20 EUKB-94-507 2CKA002111A0654 10 chalet-white 20-02 EUJ-96-507 2CKA002014A1478 10
château-black 20 EUKB-95-507 2CKA002111A0655 10
chalet-white 20 EUKB-96-507 2CKA002111A0656 10 Double SCHUKO® socket outlets )
1
shuttered
With screwless terminals.
SCHUKO® socket outlet
with hinged lid DP (2 P + E)
Delivered with special frame for IP44 protection level Suitable for 1gang flush-mounted boxes.
The IP44 protection level will achieved only if the device Rated voltage: 250 V~
is mounted on a flat and napless wall. Rated current: 16 A
With screwless terminals. white 20-02 EUJKS-92-507 2CKA002021A0379 10
DP (2 P + E) champagne 20-02 EUJKS-93-507 2CKA002021A0380 10
Rated voltage: 250 V~
Rated current: 16 A alpine white 20-02 EUJKS-94-507 2CKA002021A0378 10
white 20 EUCKD-92-507 2CKA002018A1504 10/100 château-black 20-02 EUJKS-95-507 2CKA002021A0381 10
champagne 20 EUCKD-93-507 2CKA002018A1501 10/100 chalet-white 20-02 EUJKS-96-507 2CKA002021A0382 10
1) Increased shock protection .
alpine white 20 EUCKD-94-507 2CKA002018A1505 10/100
château-black 20 EUCKD-95-507 2CKA002018A1502 10/100
SCHUKO® socket outlet ) )
2
1
chalet-white 20 EUCKD-96-507 2CKA002018A1503 10/100
with screw-type terminals
DP (2 P + E)
Socket outlet ) 1 Rated voltage: 250 V~
with earth pin Rated current: 16 A
With screwless terminals.
Suitable for the countries: Belgium, Poland, Czech ivory 2300 EUC-92-507 2CKA002011A6154 10
Republic.
DP (2 P + E) champagne 2300 EUC-93-507 2CKA002011A6146 10
Rated voltage: 250 V~ alpine white 2300 EUC-94-507 2CKA002011A6155 10
Rated current: 16 A
château-black 2300 EUC-95-507 2CKA002011A6147 10
20 M-500 2CKA002017A0854 10/100
chalet-white 2300 EUC-96-507 2CKA002011A6150 10
1) Insert can be used for all covers 2399 UCKS-xx.
1) Terminals suitable for loop through connection.
2) With screw-type terminals
