11/294 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
basic55®
Data communication

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Universal data connection unit, cat. 3 ) Universal data connection unit, RJ45, Cat. 6e,
1
1
1gang unshielded, with down-leading outlet )
With down-leading outlet. 1gang
For 8-pole plug, RJ 11/12, RJ 45, ISDN capability, Cat. 3. With down-leading outlet and LSA self-cutting clamps.
Design according to IEC 60 603-7-2:2007. Cat. 6 according to DIN EN 50173-1:2003-06, ISO/IEC
Screw contacts 1180:2002, and TIA/EIA-568-B.2:2002.
With claw. Cat. 6a (Category 6 augmented) in accordance with TIA/
Protection class (Device): IP 20 EIA-568-B.2-10 Draft 8.0.
Marking in accordance with EIA/TIA 568 A and B.
0213-507 2CKA000230A0378 1/10
Design according to IEC 60 603-7-2:2007.
1) Suitable for cover plate 1803-xxx.
Up to 250 MHz on all pairs of wires.
Suitable for Gigabit Ethernet.
With claw.
Universal data connection unit, RJ45, Cat. 6e,
unshielded, with down-leading outlet ) 1 0221-507 2CKA000230A0399 10
1gang 1) Suitable for cover plate 1803-xxx.
With down-leading outlet and LSA self-cutting clamps.
Cat. 6 according to DIN EN 50173-1:2003-06, ISO/IEC
1180:2002, and TIA/EIA-568-B.2:2002. Modular-Jack insert
Marking in accordance with EIA/TIA 568 A and B. Cat. 6 non-shielded, 8 (8)-pole
Design according to IEC 60 603-7-2:2007. For cover plate 2561-xxx, 2561-02-xxx and insert 1812,
Up to 250 MHz on all pairs of wires. 1866 built-in, 1867 built-in.
Suitable for Gigabit Ethernet. For conductor cross-sections of 0.12 mm² (AWG 26) to
With claw. 0.35 mm² (AWG 22).
Suitable for RJ 11, RJ 12 und RJ 45.
0209-507 2CKA000225A0154 1/10
0220-507-101 2CKA000230A0469 10
1) Suitable for cover plate 1803-xxx.
11
Universal data connection box with down-leading
outlet )
1
Data-connection box, RJ 45, cat. 6a iso, shielded ) 2gang internally parallel connected
1
1gang With down-leading outlet.
With down-leading outlet and LSA self-cutting clamps. For 8-pole plug, RJ 11/12, RJ 45, ISDN capability, Cat. 3.
RJ-45 terminals for networks according to Cat 6A, Class Design according to IEC 60 603-7-2:2007.
EA (10 Gbits/s / 500MHz). Screw contacts
Equates to cat. 6a, Class EA according to With claw.
ISO/IEC 11801:2011-06. Protection class (Device): IP 20
Terminal marking A and B according to TIA/EIA-568-B.2. 0214 2CKA000230A0235 10/100
Typ according to EN 60 603-7-51:2011-01.
Shielding according to DIN EN 55022, Class B. Mounting 35 mm deep flush 1gang
Up to 500 MHz on all pairs of wires. boxes: or Dual Box 3070-2/35 BSDB.
Suitable for 10-Gigabit Ethernet. 2gang product 2gang combination with adapter plate
Suitable for PoE+ according to IEEE 802.3at, >- 1.000 combinations: APBS in Dual Box only.
contact durability.
Flex cable entries from all sides without buckles. neon indicator: not applicable
Earthing of housing via 6,3 mm blade terminal at the 1) Suitable for cover plate 1803-02-xxx.
back possible.
Re-embedded proofed.
Suitable for Mix-and-Match operation. Universal data connection box with down-leading
1
Suitable for RJ 11, RJ 12 und RJ 45. outlet )
For data cables with a diameter of 6 -10 mm. 2 x outlets, 8/8-pole
For wires of AWG 24-22. With down-leading outlet.
For trunk systems, flush-mounted wall boxes and For 8-pole plug, RJ 11/12, RJ 45, ISDN capability, Cat. 3.
underfloor systems. Design according to IEC 60 603-7-2:2007.
Without claws. Screw contacts
Mounting depth: 31 mm. With claw.
Protection class (Device): IP 20 Protection class (Device): IP 20
0215 2CKA000230A0243 10
metal clad 0218/11-101-507 2CKA000230A0410 1/10
Mounting 35 mm deep flush 1gang
1) Suitable for cover plate 1803-xxx.
boxes: or Dual Box 3070-2/35 BSDB.
2gang product 2gang combination with adapter plate
combinations: APBS in Dual Box only.
neon indicator: not applicable
1) Suitable for cover plate 1803-02-xxx.
