11/322 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Sky Niessen
TV outlets

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

TV / R terminal outlet TV-R/SAT terminal outlet
TV and R double outlet - Final. TV-R and SAT double outlet - Final.
Without filter. Installation as a terminal outlet connected to a tap-off or
Installation as a terminal outlet connected to a splitter (without terminal resistor).
tap-off or splitter (without terminal resistor). Connection: screw terminal and clamp.
Connection: screw terminal and clamp. Output connectors (C1 / C2):
Output connectors (C1 / C2): IEC male 9,52 mm. diam. / IEC female 9,52 mm. diam.
IEC male 9,52mm diam. / IEC female 9,52 mm. diam. Frequency range (I/O / C1 / C2):
Frequency range (I/O / C1 / C2): 5 - 2.400 MHz / 5 - 862 MHz / 930 - 2.400 MHz.
5 - 862 MHz / 5 - 862 MHz / 5 - 862 MHz. Basic loss (FM / TV / SAT):
Basic loss (FM / DAB / VHF / UHF): 0,2±0,1 dB / 1,0 ±0,5 dB / 1,2±0,6 dB.
10,0±0,7 dB / 10,0 ±1,5 dB / 4,0±1,5 dB / 3,0±0,5 dB. Isolation (FM / TV / SAT): >45 / >14 / >14.
Isolation (FM / TV): >14 / >14. Selectivity (TV-R / SAT): >15 / >15.
Return loss (FM / TV): >18 / >10. Return loss (VR / FM / TV / SAT): >25 / >25 / >14 / >10.
Included: fixing claws. DC path (Vdc / mA / Tono):
Cover plate code: 8550. 24 max. / 500 max. / 22 KHz - DiSEqC.
Included: fixing claws.
Cover plate code: 8550.1.
8150 2CLA815000A1001 10
8151.3 2CLA815130A1001 10
TV / R final outlet - CATV outlet
TV and R double outlet - CATV outlet - Final. TV-R/SAT final outlet
With filter. TV-R and SAT double outlet - Final.
Installation as a terminal outlet connected to a tap-off or Installation as a terminal outlet connected to a series
splitter (without terminal resistor). with loop-through outlets.
Connection: screw terminal and clamp. Connection: screw terminal and clamp.
Output connectors (C1 / C2): Output connectors (C1 / C2):
IEC male 9,52 mm. diam. / IEC female 9,52 mm. diam. IEC male 9,52 mm. diam. / IEC female 9,52 mm. diam.
Frequency range (C1 / C2): Frequency range (I/O / C1 / C2):
5 - 68 & 118 - 1.000 MHz / 87,5 - 108 MHz. 5 - 2.400 MHz / 5 - 2.400 MHz / 5 - 2.400 MHz.
Basic loss (R / FM / TV): Basic loss (FM / TV / SAT):
11
0,3±0,1 dB / 1,1 ±0,3 dB / 0,9±0,3 dB. 3,7±0,3 dB / 4,0±0,5 dB / 5,0±1,2 dB.
Isolation (FM / TV): >18 / >16. Isolation (FM / TV / SAT): >20 / >20 / >14.
Selectivity (FM / TV): >10 / >18. Return loss (VR / FM / TV / SAT): >16 / >16 / >16 / >9.
Return loss (R / FM / TV): >18 / >16 / >18. DC path (Vdc / mA / Tono):
Chroma-luminance delay (ns): <10. 24 max. / 500 max. / 22 KHz - DiSEqC.
Included: fixing claws. Included: fixing claws.
Cover plate code: 8550. Cover plate code: 8550.1.
8150.3 2CLA815030A1001 10 8151.7 2CLA815170A1001 10

TV / R loop-through outlet TV-R/SAT loop-through outlet
TV and R double outlet - Intermediate. TV-R and SAT double outlet - Intermediate
Installation as an intermediate outlet in series connected Installation as an intermediate outlet in series connected
to each other. From 2nd to 4th floor. to each other.
Connection: screw terminal and clamp. Output connectors (C1 / C2):
Output connectors (C1 / C2): IEC male 9,52 mm. diam. / IEC female 9,52 mm. diam.
IEC male 9,52mm diam. / IEC female 9,52 mm. diam. Frequency range (I/O / C1 / C2):
Frequency range (I/O / C1 / C2): 5 - 2.400 MHz / 5 - 2.400 MHz / 5 - 2.400 MHz.
13 - 862 MHz / 13 - 862 MHz / 13 - 862 MHz. Basic loss (FM / TV / SAT):
Basic loss (FM / DAB / VHF / UHF): 10,0±1,0 dB / 10,0±1,0 dB / 12,0±2,0 dB.
25±1,5 dB / 25 ±1,5 dB / 8,0±0,7 dB / 8,0±0,7 dB. Through loss (FM / TV / SAT): 2,5±0,5 / 2,5±0,7 / 3,0±1,0.
Through loss (FM / VHF / UHF): Directivity (FM / TV / SAT): >20 / >12 / >5.
2,0±0,3 dB / 2,0±0,5 dB / 2,0±0,5 dB. Isolation (FM / TV / SAT): >45 / >30 / >28.
Directivity (FM / TV): >12 dB / >9 dB. Return loss (VR / FM / TV / SAT): >13 / >13 / >12 / >12.
Isolation (FM / TV): >16 / >15. DC path (Vdc / mA / Tono):
Return loss (FM / TV): >12 / >12. 24 max. / 500 max. / 22 KHz - DiSEqC.
Included: fixing claws. Included: fixing claws.
Cover plate code: 8550. Cover plate code: 8550.1.
8150.7 2CLA815070A1001 10 8151.8 2CLA815180A1001 10

Cover plate for TV/R outlet Cover plate for TV-R/SAT outlet
Cover plate for TV outlet code: 8150, 8150.3 & 8150.7. Cover plate for TV outlet code: 8151.3 , 8150.7 & 8150.8.

Soft White 8550 BL 2CLA855000A1101 20 Soft White 8550.1 BL 2CLA855010A1101 20
Silver 8550 PL 2CLA855000A1301 20 Silver 8550.1 PL 2CLA855010A1301 20
Soft Black 8550 NS 2CLA855000A1501 20 Soft Black 8550.1 NS 2CLA855010A1501 20
Stainless Steel 8550 AI 2CLA855000A1401 20 Stainless Steel 8550.1 AI 2CLA855010A1401 20
Antique Gold 8550 OE 2CLA855000A1201 20 Antique Gold 8550.1 OE 2CLA855010A1201 20
