Sky Niessen
Light controls - Rotatory dimmers

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Rotatory dimmer, RL, 20-500 W Rotatory dimmer, RC, 40-420 W
Rated voltage: 230 V~ ; ± 10% - 50 Hz. Rated voltage: 230 V~ ; ± 10% - 50 Hz.
With rotatory control, 2-way On-Off switching and soft- With rotatory control, soft-catch and with trailing edge control.
catch. Leading Edge control. Rated power: 40 - 420 W / VA.
Rated power: 20 - 500 W / VA. For incandescent lamps, 230 V tungsten halogen
For incandescent lamps, 230 V tungsten halogen lamps and low-voltage halogen lamps with electronic
lamps and low-volt halogen lamps with conventional transformers.
transformer. Low-noise, short-circuit-proof, overload-protected.
With adjustable minimum brightness. Not suitable with conventional transformers.
In the case of conventional transformers, take ~20% In case of electronic transformers, 5 % transformer losses.
transformer loss into account. Provided with terminal for net disconnection devices.
Provided with terminal for net disconnection devices. Also applicable for 1gang 2 way installations.
Also applicable for 1gang 2way installations. Included: fixing claws.
Included: fixing claws. Cover plate code: 8560.2.
Cover plate code: 8560.2.
8160.7 2CLA816070A1001 1
8160 2CLA816000A1001 1
Rotatory dimmer, RLC, 60-420 W
Rotatory dimmer, LED, 2-100 W Rated voltage: 230 V~ ; ± 10% - 50/60 Hz.
Rated voltage: 230 V~ ; ± 10% - 50/60 Hz. With soft-catch.
Nominal power: 2 - 100 W/VA (retrofit LED loads). With intelligence for universal operation.
Nominal power: 10 - 250 W/VA (non-LED loads). Rated power: 60 - 420 W / VA.
With rotatory control, 2-way switch and soft-catch. For incandescent lamps, 230 V tungsten halogen lamps
2-wire connection (neutral conductor not required). and low-voltage halogen lamps with conventional
Optimised for dimming of retrofit LED lamps (LEDi). transformers or electronic transformers.
For dimming dimmable Retrofit-LEDs (LEDi) and Short-circuit-proof, overload-protected.
dimmable Retrofit-LEDs (LEDi) with conventional or Capacity expansion via output-side, parallel connectable
electronic transformers, for incandescent lamps, 230 load line with a power module 6594 U up to 735 W/VA
V tungsten halogen lamps, low-voltage halogen lamps possible.
with conventional or electronic transformers and Remote operation via rotatory-type remote control 8161.8 possible.
dimmable energy-saving halogen lamps. In case of electronic transformers, 5 % transformer losses.
Mix operation of LEDi with conventional loads possible. In the case of conventional transformers, take ~20%
Switch adjustable: leading and trailing edge control. transformer loss into account. 11
Low-noise level by MOSFET transistors. Cannot be combined with a 2way switch.
With electronic short-circuit and overload protection. Included: fixing claws.
With adjustable minimum brightness. Cover plate code: 8560.2.
Temperature range device: 0 °C to 35 °C.
In the case of conventional transformers, take ~20%.
transformer loss into account. 8160.8 2CLA816080A1001 1
In case of electronic transformers, 5 % transformer losses.
Also applicable for 1gang 2way installations.
Provided with terminal for net disconnection devices. Rotatory dimmer, 1-10Vdc
Included: fixing claws. Rated voltage: 230 V~ ; ± 10% - 50/60 Hz.
Cover plate code: 8560.2. Rated power: 700 W / VA.
With rotatory control.
8160.2 2CLA816020A1001 1 For controlling ballast units for fluorescent lamps with
control output 1-10 V DC, control current max. 50 mA DC.
For LED control via control drivers.
Without cover plate.
Rotatory dimmer, RL, 200-700 W Not illuminable.
Rated voltage: 230 V~ ; ± 10% - 50 Hz. Making-current limiters have to be provided in case of
With rotatory control, 2way On-Off switching and soft- too high making currents.
catch. Leading Edge control. Included: fixing claws.
Rated power: 200 - 700 W / VA. Cover plate code: 8560.2.
For incandescent lamps, 230 V tungsten halogen lamps and
low-volt halogen lamps with conventional transformer. 8160.9 2CLA816090A1001 1
Short-circuit-proof, overload-protected.
With adjustable minimum brightness.
Without cover plate.
Without fixing claws. Rotatory dimmer remote control
In the case of conventional transformers, take ~20%. Rated voltage: 230 V~ ; ± 10% - 50/60 Hz.
transformer loss into account. To be used with dimmer code 8160.8.
Provided with terminal for net disconnection devices. With soft-catch.
Cover plate code: 8560.2. A maximum of 5 multi-way extensions can be connected
to a 8160.8 dimmer.
Included: fixing claws.
8160.3 2CLA816030A1001 1 Cover plate code: 8560.2.
8161.8 2CLA816180A1001 1
Rotatory dimmer, RL, 60-400 W
Rated voltage: 230 V~ ; ± 10% - 50 Hz.
1 channel designed as dimmer.
1 channel designed as switch contact (1-gang 2-way Cover plate with rotatory knob for dimmer
contact element) with leading edge control. Cover plate with rotatory knob for dimmer code:
Rated power: 60 - 400 W / VA.
For incandescent lamps, 230 V tungsten halogen lamps and 8160, 8160.2, 8160.3, 8160.5, 8160.7, 8160.8, 8160.9 &
low-volt halogen lamps with conventional transformer. 8161.8.
With adjustable minimum brightness. Included: indicator neon lamp.
Rated current 6A (changeover contact switch output).
In the case of conventional transformers, take ~20%
transformer loss into account. Soft White 8560.2 BL 2CLA856020A1101 5
Can be used to replace a 2 gang 1 way switch.
Included: fixing claws. Silver 8560.2 PL 2CLA856020A1301 5
Cover plate code: 8560.2
Soft Black 8560.2 NS 2CLA856020A1501 5
8160.5 2CLA816050A1001 1 Stainless Steel 8560.2 AI 2CLA856020A1401 5
Antique Gold 8560.2 OE 2CLA856020A1201 5
