11/340 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Sky Niessen - Free@home - Home automation
Room temperature controller Wireless sensors

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

free@home Room temperature controller free@home Sensor unit - 1-gang - Wireless
Control element with room temperature control function Rated voltage: 230 Vac - 50/60Hz.
for controlling commercially available actuating drives For transmitting switching, push-button, dimming and
or analogue actuating drives (continuous controllers), as blind commands to an ABB-free@home® actuator.
well as fan coils. With display of setvalue temperature. Wireless communication with the free@home system.
Display elements: LCD Display showing operation modes. With fixing claws.
Mounting depth: 14 mm. Control element: switch contacts top/bottom.
To be installed with CP-RTC-85 cover plates for RTC or Display elements: LED as light for orientation or display
CP-RTC-FC-85 cover plates for fan coil control. of the switching state.
Temperature range device: -5 °C to 45 °C.
Mounting depth: 32 mm.
To be installed with SR-1-85 cover plates.
RTC-F-1 2CKA006220A0122 1
Motion sensor & actuators SU-F-1.0.1-WL 2CKA006200A0072 1

Product Article-No. Order-No. Pack/Qty
free@home Sensor unit - 2-gang - Wireless
free@home 180° motion sensor Rated voltage: 230 Vac - 50/60Hz.
With select lens for detection with animal access. For For transmitting switching, push-button, dimming and
automatic switching of ABB-free@home® actuators blind commands to an ABB-free@home® actuator.
dependent on movement and brightness. Wireless communication with the free@home system.
To be used with. With fixing claws.
Detection range: frontal 6 m, lateral 3 m. Control element: switch contacts top/bottom.
Detection angle: 180°. Display elements: LED as light for orientation or display
Brightness limit value: 1 – 500 lux. of the switching state.
Protection class of device: IP 20. Temperature range device: -5 °C to 45 °C.
11
Mounting depth: 14.1 mm. Mounting depth: 32 mm.
To be installed with CP-MD-85 cover plates (mounting To be installed with SR-2-85 cover plates.
grid without claws included).
MD-F-1.0.PB.1 2CKA006220A0229 1
SU-F-2.0.1-WL 2CKA006200A0073 1
free@home 180° motion sensor/actuator free@home Sensor/Switch actuator - 1/1-gang - Wireless
With select lens for detection with animal access. Rated voltage: 230 Vac - 50/60Hz.
Including an integrated actuator for switching 230 V~ For switching 230 V~ consumers.
devices. Wireless communication with the free@home system.
Outputs: 1× normally open contact, potential free. With integrated switch actuator. Switching function
Suitable for: resistive. is available also without prior programming (pre-
Rated current: 10 A. configured).
Rated power: 2300 W. Configuration can be changed later via the web interface
Suitable for: capacitive. (groups, scenes, etc.).
Rated current: 10 AX. 3 wire connection (neutral conductor required).
Detection range: frontal 6 m, lateral 3 m. With 230 V extension unit input (On/Off).
Detection angle: 180°. With fixing claws.
Brightness limit value: 1 – 500 lux. Control element: switch contacts top/bottom.
Protection class of device: IP 20. Display elements: LED as light for orientation or display
Mounting depth: 31.5 mm. of the switching state.
To be installed with CP-MD-85 cover plates Outputs: 1 Normally Open contact, potential-bound
(mounting grid without claws included).
(output voltage: 230 Vac)
Suitable for: ohmic.
MSA-F.1.1.PB.1 2CKA006220A0231 1
Rated current / power: 10 A / 2300 W.
Suitable for: capacitive.
Rated current / power: 10 AX / 2300 VA.
Suitable for: inductive.
Rated current / power: 10 A / 2300 VA.
Temperature range device: -5 °C to 45 °C.
Mounting depth: 32 mm.
To be installed with SR-1-85 cover plates.

SSA-F-1.1.1-WL 2CKA006200A0074 1
