Sky Niessen
Multiroom Bluetooth system FM radio with alarm

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Multiroom sound module FM-radio and alarm module - 2M
Rated voltage: 127-230 Vac ± 15%; 50-60 Hz. Rated voltage: 230 Vac ± 15%; 50-60 Hz.
Max. consumption: 200 mA. Max. consumption: 100 mA.
Stand-by consuption: 0,3W. Stand-by consuption: 0,2W.
Amplifier power: 6+6 W; <1% distorsion (4 Ω). Amplifier power: 2+2 W; <1% distorsion (16 Ω).
Speaker impedance: 4 Ω (2+2 W audio). Speaker impedance: 16 Ω (2+2 W audio).
FM radio digital tuner with RDS. FM radio digital tuner with RDS.
Alarm clock with buzzer, radio types and snooze function. Alarm clock with buzzer, radio types and snooze function.
Bluetooth receiver: Bluetooth® v2.1 2.4GHz IEEE 802.15.1. Optional: auxilary module 9368.3 for I/O (1 mini-jack
Multiroom function available (1 master device and up to stereo input & 1 mini-jack stereo output), USB connection
14 slave devices). and Bluetooth receiver functions.
Remote control using code 9368.2 (ZigBee 2.4GHz IEEE Mounting grid delivered with the cover plate (without
802.15.4). fixing claws).
Optional: auxilary module 9368.3 for I/O (1 mini-jack Cover plate code: 8568.
stereo input & 1 mini-jack stereo output) and USB
connection functions.
9368 2CLA936800A1001 1
9368.1 2CLA936810A1001 1 FM-radio and alarm module - 2M
Rated voltage: 127 Vac ± 15%; 50-60 Hz.
Max. consumption: 100 mA.
Remote control for multiroom sound module - 2M Stand-by consuption: 0,2W.
Rated voltage: 127-230 Vac ± 15%; 50-60 Hz. Amplifier power: 2+2 W; <1% distorsion (16 Ω).
Max. consumption: 15 mA. Speaker impedance: 16 Ω (2+2 W audio).
Stand-by consuption: 0,5W. FM radio digital tuner with RDS.
To control 9368.1 module (1 remote control for each Alarm clock with buzzer, radio types and snooze function.
module). Optional: auxilary module 9368.3 for I/O (1 mini-jack 11
Wireless connection between moles 9368.1 and 9368.2 stereo input & 1 mini-jack stereo output), USB connection
(ZigBee 2.4GHz IEEE 802.15.4). and Bluetooth receiver functions.
Optional: auxilary module 9368.3 for I/O (1 mini-jack Mounting grid delivered with the cover plate (without
stereo input & 1 mini-jack stereo output) and USB fixing claws).
connection functions. In case of using 9368.3 module, the Cover plate code: 8568.
connection between modules 9368.1 and 9368.2 must be
wired (3 wires).
Mounting grid delivered with the cover plate (without 9368.7 2CLA936870A1001 1
fixing claws).
Cover plate code: 8568.
Cover plate for radio/remote control modules
Cover plate for FM-radio module and for remote control
9368.2 2CLA936820A1001 1
module code: 9368, 9368.2 & 9368.7.
Included: cover plate and mounting grid.
Cover plate for radio/remote control modules Without fixing claws.
Cover plate for FM-radio module and for remote control
module code: 9368, 9368.2 & 9368.7. Soft White 8568 BL 2CLA856800A1101 1
Included: cover plate and mounting grid.
Without fixing claws. Silver 8568 PL 2CLA856800A1301 1
Soft Black 8568 NS 2CLA856800A1501 1
Soft White 8568 BL 2CLA856800A1101 1 Stainless Steel 8568 AI 2CLA856800A1401 1
Silver 8568 PL 2CLA856800A1301 1 Antique Gold 8568 OE 2CLA856800A1201 1
Soft Black 8568 NS 2CLA856800A1501 1
Stainless Steel 8568 AI 2CLA856800A1401 1
Antique Gold 8568 OE 2CLA856800A1201 1
