11/370 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Impressivo
Rocker switches, push switches

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

1-gang rockers with red lens, IP21/IP44 Screw-mounted rocker frames, IP44
1-gang rockers for all 1-gang switch inserts. Flush- and Screw-mounted rocker frames are used with the seals
surface mounting: Protection class IP21, and IP44 with 2463 or 2464 to reach IP44 protection class on
a seal and screw fastening rocker frame. The rockers switches and push switches. Furthermore, it can be
contain a red lens. used to connect the switch frame to the insert for
improved security.
Switch rocker, 1-gang, red lens Supporting frame for 1/3-gang rocker, screw fastening
white 1789-84 2TKA000559G1 1/10 2474 2TKA000004G1 20/200
Switch rocker, 1-gang, red lens Supporting frame for 2-gang rocker, screw fastening
anthracite 1789-81 2TKA000557G1 1/10 2475 2TKA000005G1 20/200
Switch rocker, 1-gang, red lens
aluminium 1789-83 2TKA000558G1 1/10 Lamps for switches
Lamps for switches and push buttons. Lamps can be
1-gang rockers with transparent lens and ''light'' installed in 1-gang switch inserts that include the
symbol, IP21/IP44 signal-/search light possibility. Lamps can't be installed
1-gang rockers for all 1-gang switch inserts. Flush- and in 2- or 3-gang switch inserts.
surface mounting: Protection class IP21, and IP44 with
a seal and screw fastening rocker frame. The rocker Lamp, 230V/0.4mA, fluorescent, for 1-gang switches
contains transparent lens and "Light" symbol. 8370 2TKA000045G1 10/100
white 1789LI-84 2TKA000569G1 1/10 Lamp, 230V/2mA, fluorescent, for 1-gang switches
anthracite 1789LI-81 2TKA000567G1 1/10 8372 2TKA000047G1 10/100
aluminium 1789LI-83 2TKA000568G1 1/10 Lamp, 24V/22mA, incandescent, for 1-gang switches
8375 2TKA000048G1 10/100
11
Lamp, 12V/40mA, incandescent, for 1-gang switches
1-gang rockers with transparent lens and ''key''
symbol, IP21/IP44 8376 2TKA000049G1 10/100
1-gang rockers for all 1-gang switch inserts. Flush- and Lamp, 230V/1.5mA, fluorescent, for card switch
surface mounting: Protection class IP21, and IP44 with 8331 2TKA000042G1 10/100
a seal and screw fastening rocker frame. The rocker
contains transparent lens and "key" symbol. Lamp, 250V/0.4mA, LED, for 1-gang switches
8370R 2TKA00003241 10/100
white 1789TR-84 2TKA000574G1 1/10
Lamp, 5-24V/0,5-2,5mA, LED, for 1-gang switches
anthracite 1789TR-81 2TKA000572G1 1/10 8375R 2TKA00003242 10/100
aluminium 1789TR-83 2TKA000573G1 1/10

1-gang rockers with transparent lens and ''bell''
symbol, IP21/IP44
1-gang rockers for all 1-gang switch inserts. Flush- and
surface mounting: Protection class IP21, and IP44 with
a seal and screw fastening rocker frame. The rocker
contains transparent lens and "bell" symbol.
white 1789KL-84 2TKA000564G1 1/10
anthracite 1789KL-81 2TKA000562G1 1/10
aluminium 1789KL-83 2TKA000563G1 1/10

Seal for switches, IP44
Seal for 85mm cover frame. Switches and push
switches are IP21 when installed on a rough surface
with a seal. Protection class is IP44 when using
screw-mounted rocker frame with a seal.
2463 2TKA000002G1 20/200
